RF Components

 KEY SPECIFICATIONSBandKa-BandColourFS33446External Ref Freq10 MHz (sine-wave), - 5 to +5 dBmInput Frequency Band 120.20 - 21.20 GHzLO Frequency 119.25 GHzLO TypeEXTNoise Figure Max1.6 dBNoise Figure Typ1.5 dBNumber Of Onboard LosSingle-BandOutput...

 KEY SPECIFICATIONSBandX-BandColourFS34083External Ref Freq10 MHz (sine-wave), - 5 to +5 dBmInput Frequency Band 17.25 - 7.75 GHzLO Frequency 16.30 GHzLO TypeEXTNoise Figure Max0.8 dBNoise Figure Typ0.7 dBNumber Of Onboard LosSingle-BandOutput...

 KEY SPECIFICATIONSInput Frequency Band 13.40 - 4.20 GHzRF SPECIFICATIONSInsertion Loss0.04 dB maxRejection70 dB typRejection Range5.825 - 6.725 GHzVSWR1.25 : 1 max.INTERFACE SPECIFICATIONSIF Output ConnectorCPR 229FRF Input ConnectorCPR 229G...
