RF Components

 KEY SPECIFICATIONSBandKu-BandInput Frequency Band 111.70 - 12.20 GHzLO Frequency 110.75 GHzNoise Figure Max0.9 dBNoise Figure Typ0.8 dBNumber Of Onboard LosSingle-BandOutput Frequency Band 1950 - 1450 MHzRF SPECIFICATIONSConversion Gain Max70...

 KEY SPECIFICATIONSMTBF711 Khrs, MIL-HDBK-217FOutput Power Rated100 WELECTRICAL SPECIFICATIONSEfficiency90% typ.Input Current1.4A / 115 VAC , 1.0A / 230 VACInput Voltage Range90 - 264 VAC, 125 - 373 VDCOutput Current Range0 - 4.5 AOutput Current...

 KEY SPECIFICATIONSOutput Power Rated321.6 WELECTRICAL SPECIFICATIONSEfficiency87% typ.Input Current5A / 115 VAC , 2.5A / 230 VACInput Voltage88 - 264 VAC, 124 - 370 VDC (withstand 300VAC surge for 5 sec. w/out damage)Output Dc Voltage48VOutput...

 KEY SPECIFICATIONSBandL-BandPass BandL-Band Pass Through: 950 - 1450 MHzRF SPECIFICATIONSInput VSWRL-Band Pass Through: 2.0 : 1 max.Insertion Loss10 MHz Injection: 1 dB max. L-Band Pass Through: 7 dB max. with 50/75 ohms transformationOutput...

 KEY SPECIFICATIONSBandKu-BandExternal Ref Freq10 MHz (sine-wave), - 5 to +5 dBmLO Frequency11.80 GHzLO Stability± 0.1 ppmOperating IF Frequency950 - 1450 MHzOperating RF Frequency12.75 - 13.25 GHzOutput Power Rated40WRF SPECIFICATIONSAM/PM...

 KEY SPECIFICATIONSTone Amplitude0.55 ~ 0.9 vppTone Frequency20 ~ 24 kHzELECTRICAL SPECIFICATIONSCurrent Consumption500 mA max.Power Requirements+23 to +25 V DCINTERFACE SPECIFICATIONSBand SelectionBand Select by Rotary SW: Band 1: 13 VDC Band 2: 13...

 KEY SPECIFICATIONSBandKu-BandExternal Ref Freq10 MHz (sine-wave), - 5 to + 5 dBmInput Frequency Band 1950 - 1700 MHzLO Frequency 111.80 GHz and 12.05 GHzOutput Frequency Band 112.75 - 13.50 GHzOutput Power Rated40WRF SPECIFICATIONSGain Flatness...

 KEY SPECIFICATIONSBandKu-BandExternal Ref Freq10 MHz (sine-wave), - 5 to + 5 dBmInput Frequency Band 1Band 1: 950 - 1700 MHz Band 2: 950 - 1450 MHzLO StabilityBand 1: 12.05 GHz Band 2: 11.80 GHzOutput Frequency Band 1Band 1: 13.00 - 13.50 GHz Band...

 KEY SPECIFICATIONSBandC-BandColourFS36231External Ref Freq10 MHz (sine-wave), - 10 to 0 dBmInput Frequency Band 13.40 - 4.20 GHzLO Frequency 15.15 GHzLO TypePLLNoise Figure Max25K Noise Figure Typ20KNumber Of Onboard LosSingle-BandOutput Frequency...

 KEY SPECIFICATIONSBandKu-BandExternal Ref Freq10 MHz (sine-wave), - 5 to +5 dBmFrequency SenseNon-invertedInput Frequency Band950 - 1750 MHzLO Frequency10.75 GHzOutput Frequency Band11.70 - 12.50 MHzOutput Power Rated4 WRF SPECIFICATIONSGain...
