RF Components

 KEY SPECIFICATIONSAntenna Aperture2.4mAntenna CategoryDrive AwayBandKa-BandANTENNA SPECIFICATIONSACU Size19” Rack 1U sizeAntenna Input Power100 - 240 AC, 50/60 HzAntenna TypeDual OffsetAuto AcquisitionInitial acquisition satellite time: ≤ 3...

 KEY SPECIFICATIONSBandKu-BandANTENNA SPECIFICATIONSAntenna TypeRing FocusCross Polarization Isolation35 dBPolarizationLinearSidelobeFirst sidelobe ≤ -14 dBRF SPECIFICATIONSPort Isolation Rx-Tx85dBRx Frequency10.70 - 12.75 GHzRx Gain41.5+20lg(f/12...

 KEY SPECIFICATIONSBandKu-BandANTENNA SPECIFICATIONSAntenna TypeDual OffsetCross Polarization Isolation35 dBPolarizationLinearSidelobeFirst sidelobe ≤ -14 dBRF SPECIFICATIONSPort Isolation Rx-Tx85dBRx Frequency10.70 - 12.75 GHzRx Gain47.2+20lg(f/12...

 KEY SPECIFICATIONSAntenna Aperture0.9mAntenna CategoryManual FlyawayBandKa-BandANTENNA SPECIFICATIONSAntenna TypeRing FocusAxial Ratio1.5 dBMotion Range AZ360°Motion Range EL0° - 90°PolarizationCircularSidelobeFirst sidelobe ≤ -14 dBRF...

 KEY SPECIFICATIONSAntenna CategoryAuto FlyawayBandKa-BandANTENNA SPECIFICATIONSAntenna Aperture2.4mAntenna TypeFeed ForwardCross Polarization Isolation25 dBMotion Range AZ±220°Motion Range EL0° - 90°PolarizationCircularSidelobe≤-14dBRF...

 KEY SPECIFICATIONSBandKu-BandANTENNA SPECIFICATIONSAntenna TypeFeed ForwardCross Polarization Isolation30 dBPolarizationLinearSidelobe≤-14dBRF SPECIFICATIONSPort Isolation Rx-Tx≥85dBPort Isolation Tx-Rx≥40dBRx Frequency10.70 - 12.75 GHzRx...

 KEY SPECIFICATIONSAntenna Aperture4.5mBandC-BandReflector MaterialAluminum MeshANTENNA SPECIFICATIONSAntenna Drive Modemanual structure antennaAntenna TypePrime FocusNumber Of Ports1-portPolarizationLinearRF SPECIFICATIONSFrequency4.4 - 5.0...

 KEY SPECIFICATIONSBandKu-BandReflector Diameter1.8 mReflector MaterialGlass Fiber Reinforced Polyester SMCANTENNA SPECIFICATIONSAntenna TypePrime Focus, OffsetAzimuth Range360° Continous, ±45° Fine AdjustmentCross Polarization Isolation25 dB on...
