RF Components

 KEY SPECIFICATIONSBandKa-BandInput Frequency Band 119.20 - 20.20 GHzLO Frequency 118.25 GHzLO TypePLLNoise Figure Max1.6 dBNumber Of Onboard LosSingle-BandOutput Frequency Band 1 950 - 1950 MHzRF SPECIFICATIONSConversion Gain Max65 dBConversion...

 KEY SPECIFICATIONSBandC-BandInput Frequency Band 13.70 - 4.20 GHzLO Frequency 15.15 GHzLO TypePLLNoise Temperature Typ25KNumber Of Onboard LosSingle-BandOutput Frequency Band 1 950 - 1450 MHzRF SPECIFICATIONSConversion Gain Max65 dBConversion Gain...

 KEY SPECIFICATIONSBandKu-BandInput Frequency Band 110.95 - 12.75 GHzLO Frequency 110.00 GHzLO TypePLLNoise Figure Max1 dB Noise Figure Typ0.8 dBNumber Of Onboard LosSingle-BandOutput Frequency Band 1 950 - 2750 MHzRF SPECIFICATIONSConversion Gain...

 KEY SPECIFICATIONSBandKu-BandInput Frequency Band 110.70 - 12.20 GHzLO Frequency 19.75 GHzLO TypePLLNoise Figure Max1 dB Number Of Onboard LosSingle-BandOutput Frequency Band 1 950 - 2450 MHzRF SPECIFICATIONSConversion Gain Max65 dBConversion Gain...

 KEY SPECIFICATIONSBandKu-BandColorWhiteExternal Ref Freq10 MHz (sine-wave), - 5 to +5 dBmInput Frequency Band 1950 - 1200 MHzInput Frequency Band 21700 – 1950 MHzLO Frequency 112.05 GHzLO Frequency 212.05 GHzOutput Frequency Band 113.00 - 13.25...

 KEY SPECIFICATIONSBandKu-BandColorWhiteExternal Ref Freq10 MHz (sine-wave), - 5 to +5 dBmInput Frequency Band 1950 - 1750 MHzLO Frequency 112.80 GHzOutput Frequency Band 113.75 - 14.55 GHzOutput Power Rated2WRF SPECIFICATIONSGain Flatness (Over Any...
