RF Components

 KEY SPECIFICATIONSBandKu-BandInput Frequency Band 110.70 - 12.75 GHzNoise Figure Max At Over Temperature1.1 dBNoise Figure Max At Room Temperature0.9 dBOutput Frequency Band 110.70 - 12.75 GHzRF SPECIFICATIONSConversion Gain Max63 dBConversion Gain...

 KEY SPECIFICATIONSBandKa-BandExternal Ref Freq10 MHz (sine-wave), - 5 to +5 dBmInput Frequency Band 119.20 - 20.20 GHzLO Frequency 118.25 GHzLO TypePLLNoise Figure Max1.6 dBNoise Figure Typ1.5 dBNumber Of Onboard LosSingle-BandOutput Frequency Band...

 APPLICATIONS• Rejects terrestrial interference in C-Band (Wimax, Radar and C-Band transmitter and 5G)• Compact, low weight• Easily installed between the feed and LNB• Suitable for use with Norsat’s C-Band LNBs• Environmentally sealed and moisture...

 ANTENNA SPECIFICATIONS1St Sidelobe Azimuth Tx< -11.0 dB1St Sidelobe Elevation Tx< -11.0 dBAzimuth (H-Plane) BeamwidthTx: 2.9 ± 0.3° @ 14.0 GHzRx: 3.5 ± 0.3° @ 11.5 GHzCross Polarization-30 dB maxEIRP-SD @ 14.2 Ghz36.7 dBW/ 40 KHzElevation...

 KEY SPECIFICATIONSBandC-BandColorFS36231Input Frequency Band 13.90 - 4.20 GHzLO Frequency 15.15 GHzNumber Of Onboard LosSingle-BandOutput Frequency Band 1 950 - 1250 MHzProduct Family3000-BPF SeriesRejection Range< 3.8 GHz and > 4.8 GHzRF...
