RF Components

The model VZB2788A1 is a self contained 95 GHz Emitter consisting of an air-cooled Extended Interaction Klystron (EIK), power supply, cooling system, input and output RF components, and supporting electronics for control, monitoring and system protection...

Plays in the RainProvides up to 750 watts of power in a rugged and compact weatherproof package, digital ready, for wideband, single- and multi-carrier satellite service within the 27.0 – 31.0 GHz frequencyband. Ideal for transportable and fixed...

The model VPW2888 is a light weight and compact power supply modulator intended to operate a wide range of CPI pulsed Extended Interaction Klystrons (EIKs) in a high altitude envi- ronment.The power supply modulator (PSM) is fully encapsulated in epoxy...

CPI EPC, model VPW2827, is designed and tested to operate a wide variety of CPI CW Extended Interaction Klystrons and Oscillators.Our EPC architecture provides optimum protection for the EIK and worry free operation for the user.EIK operating parameters...

RF and ElectricalFrequency 24.75 to 25.25 GHzBandwidth 500 MHzOutput Power 700 WGain 45 dBBeam Voltage 7.5 kVBeam Current 500 mA Benefits:• Designed specifically for BSS Reverse band uplinks• Compact, rugged design• Field-proven MTBF:...

Model VKY2492 is a series of liquid cooled pulsed Extended Interaction Klystrons used for radar, instrumentation and scientific applications.Frequencies are available from 250 GHz to 276 GHz producing from 10 to 25 Watts peak power with a –6dB...

Model VKQ2471 is a series of conduction cooled pulsed Extended Interaction Klystrons used for radar, instrumentation and scientificapplications.Frequencies are available from 34.5 GHz to 35.5 GHz typically producing 2500 Watts peak power with a 1dB...

Model VKQ2470 is a series of air cooled pulsed Extended Interaction Klystrons used for radar, instrumentation and scientific applications. Frequencies are available from 31 GHz to 38 GHz typically producing 3500 Watts peak power with a 1dB bandwidth of...

The VKB 2469 series of Pulsed Extended Interaction Amplifiers (EIA) are targeted for W-Band coherent and non-coherent radar and instrumentation applications. Each ELA delivers in excess of 1 kW of peak power at typical bandwidths (-3 dB) of 500 MHz.The...
