Waveguide

WG23 / WR22 / R400 Ka Band (38-40GHz) waveguide band pass filter (39000 CF) with ≤2.5 dB insertion loss ≥14 dB return loss. Rejection is ≥60 dB 36000 MHz & 42000 MHz 10W Fitted with K-type 2.92mm RF...

Ka band waveguide bandpass filter (18.0 – 18.9 GHz) with SMA connectors, ≥30dB rejection at 17.8 GHz. 1 dB insertion loss.   Specification Description Model

WG17 / WR75 / R120 Ku-band (12250 - 12750 MHz) with 1.5 dB insertion loss across pass band 18 dB Return loss min. 20 dB min rejection @ 12800 MHz and 1 W power handling fitted with UBR120 flanges

WG17 / WR75 / R120 Ku-band (13750-14500 MHz) Waveguide filter. ≥60 dB rejection @13175 MHz and 15075 MHz. Fitted with UBR120 Flanges.

WG11A / WR229 / R40 C-band (3.4-4.2 GHz) Waveguide filter with CPR229F flanges.

C-band waveguide bandpass filter (3717.50 - 3722.50 MHz) with 1.1 dB max insertion loss and rejection ≥ 15dB @ 3500-3600 MHz, ≥ 20dB @ 3600-3700 MHz, ≥ 20dB @ 3752-3800 MHz. Fitted with CPR229G &...

ETL Systems offer Flexible Twist Waveguide starting at lengths of 100mm up to 3000mm, available in aluminium, brass or copper waveguide with aluminium, brass or tin plated flanges; covering frequency...

Rigid Waveguide Extensions Made to order rigid waveguide extensions are available in WR-28 (R320) through WR-340 (R26) waveguide sizes. Manufactured from copper or aluminum waveguide with brass or...

Rigid Waveguide Extensions Made to order rigid waveguide extensions are available in WR-28 (R320) through WR-340 (R26) waveguide sizes. Manufactured from copper or aluminum waveguide with brass or...

Seamless Flexible Non Twistable Waveguide Flexible and twistable rectangular waveguides are used in a wide variety of satcom, VSAT and telecom applications that carry high frequency radio (microwave...

AF137036 - 3ft C-Band Flex Waveguide    This 3ft (36 inch) C-Band flex waveguide (WR137)is uniquely designed to be a high quality but cost effective solution for the satellite communications market,...
