Peplink PLS-24-H2G-410W 24 PoE 2.5G Switch
Product Code:
PLS-24-H2G-410W
Weight:
4.10 KGS
Width:
26.00
(cm)
Height:
4.50
(cm)
Depth:
44.00
(cm)
$799.00
Peplink 24 Port Switch: Power and Performance Redefined
Elevate your network infrastructure with the new Peplink 24 Port Switch. Designed to meet the demands of modern businesses, this switch offers a perfect blend of power, speed, and versatility.
Key Features:
Key Features:
- 16x 1GE (802.3at PoE+) RJ45 ports
- 8x 2.5GE (802.3at PoE+) RJ45 ports
- 4x 10GE SFP+ ports
- 410W PoE power budget
*Note: Currently, these Switches can only be configured through InControl. However, a new feature for our Peplink routers, the Switch Controller, will be available soon, enabling offline local management of multiple Switches without the need for InControl.
| Technical Specifications | |
| Interface | 16x 1GE l 802.3at PoE+ 8x 2.5GE l 802.3at PoE+ 4x 10GE |
| Switch Capacity | 152 Gbps |
| Max. Packet Forwarding Rate | 216 Mpps |
| MAC Address Table | 16 |
| Power Supply | 1x Internal PSU (480W) |
| Power Input | 1x 100V – 240V AC |
| Power Consumption | 38W (System) |
| Total PoE Power Budget | 410W |
| Dimensions (D x W x H) | 10.3 x 17.3 x 1.8 inches (260 x 440 x 45 mm) |
| Weight | 9.0 pounds / 4.1 kg |
| Operating Temperature | 32° – 122°F / 0° – 50°C |
| Humidity | 15% – 95% (non-condensing) |
| Certification | FCC, CE, RoHS |
| Warranty | 1-Year Limited Warranty |
| Package Content | 1x 24 PoE 2.5G Switch 1x Power Cord 1x Screw Set 1x Rubber Foot Pad Set 1 Pair of Mounting Brackets |
| Management/Configuration | InControl |
