WERBEL MICROWAVE
WERBEL MICROWAVE WM3PD-6-18-S Power Divider, 3-way, 6-18GHz, SMA Female
Product Code:
WM3PD-6-18-S
Condition:
New
Weight:
0.10 KGS
Width:
3.99
(cm)
Height:
3.99
(cm)
Depth:
0.97
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
WM3PD-6-18-S is a 3-way Wilkinson divider that operates from 6 to 18 GHz. It is part of Werbel Microwave’s catalog of splitters that offer a wide range of port count and frequency ranges. Its compact aluminum enclosure measures 1.57 x 1.57 x 0.38 inches. The device is RoHS compliant, however it may be specially ordered with lead solder. Return loss 14dB typical input, 15dB typical output. Insertion loss above 4.8dB is 0.3dB typical. Isolation 23 dB typ. Phase balance 3.4 degrees typical. Designed, assembled and tested in USA.
| Name | No. of Outputs | Frequency Low (MHz) | Frequency High (MHz) | Isolation dB Typ. | Insertion Loss dB Typ. | Input Power as Splitter W Max. | Connectors |
| WM3PD-6-18-S | 3 | 6000 | 18000 | 23 | 0.3 | 10 | SMA |
5 customers are viewing this product
Details
WM3PD-6-18-S is a 3-way Wilkinson divider that operates from 6 to 18 GHz. It is part of Werbel Microwave’s catalog of splitters that offer a wide range of port count and frequency ranges. Its compact aluminum enclosure measures 1.57 x 1.57 x 0.38 inches. The device is RoHS compliant, however it may be specially ordered with lead solder. Return loss 14dB typical input, 15dB typical output. Insertion loss above 4.8dB is 0.3dB typical. Isolation 23 dB typ. Phase balance 3.4 degrees typical. Designed, assembled and tested in USA.
| Name | No. of Outputs | Frequency Low (MHz) | Frequency High (MHz) | Isolation dB Typ. | Insertion Loss dB Typ. | Input Power as Splitter W Max. | Connectors |
| WM3PD-6-18-S | 3 | 6000 | 18000 | 23 | 0.3 | 10 | SMA |
