Taoglas
Taoglas GuardianX 8in1 1*Active GNSS, 4*5G/4G MIMO & 3*Wi-Fi MIMO Low Profile Antenna
Product Code:
MA9908.A.002.wm
Condition:
New
Weight:
0.75 KGS
Width:
16.00
(cm)
Height:
16.50
(cm)
Depth:
36.00
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
The Taoglas GuardianX MA9908.A.002.wm is a low profile heavy-duty, fully IP67 waterproof external antenna. Combining 8 elements into one antenna, 1 GPS/GLONASS/Galileo, 4* 5G/4G/3G/2G MIMO (600MHz to 6GHz) and 3* Dual-band Wi-Fi® MIMO 2.4-5.8GHz.
Typical applications include:
- Passenger Bus / Rail / Air Applications.
- Automotive and Heavy Equipment Vehicle Tracking and Telematics
- Remote Asset and Pipeline Monitoring
- HD Video over LTE
- First Responder and Emergency Services
- M2M Applications/IoT
LTE 4G applications demand high-speed data uplink and downlink. High efficiency and high gain MIMO antennas are necessary to achieve the required signal to noise ratio and throughput required to solve these challenges. Taoglas also takes care to have high isolation between the two MIMO antennas to prevent self-interference. Low loss cables are used to keep efficiency high over long cable lengths. In contrast, smaller MIMO antennas with poorer quality thinner cables will have much-reduced efficiency and isolation, which would lead to a large drop in system throughput, increased number of drops, and may indeed not make a system connection at all.
| TECHNICAL SPECIFICATION | |
| Name | Value |
| Technology | External Antennas, Combination |
| IP Rating | IP67 |
| Impedance | 50 |
| Minimum Operating Temperature (℃) | -40 |
| Maximum Operating Temperature (℃) | 85 |
| Mounting Style | Wall |
| Termination Style | Connector |
| Antenna Connector Type | FAKRA |
| Length (mm) | 360 |
| Width (mm) | 160 |
| Height (mm) | 16.5 |
| Cable Type | TGC-200 |
| Connector Body Style | Straight |
| Polarity | RHCP, Linear |
| Frequency Range | 600MHz - 6000MHz |
| Connector Polarity | Normal |
| Cable Length (mm) | 1000 |
| VSWR | 02:01 |
| Weight (g) | 750 |
| RoHS | Yes |
| Gain (Max) | 2.46 |
5 customers are viewing this product
Details
The Taoglas GuardianX MA9908.A.002.wm is a low profile heavy-duty, fully IP67 waterproof external antenna. Combining 8 elements into one antenna, 1 GPS/GLONASS/Galileo, 4* 5G/4G/3G/2G MIMO (600MHz to 6GHz) and 3* Dual-band Wi-Fi® MIMO 2.4-5.8GHz.
Typical applications include:
- Passenger Bus / Rail / Air Applications.
- Automotive and Heavy Equipment Vehicle Tracking and Telematics
- Remote Asset and Pipeline Monitoring
- HD Video over LTE
- First Responder and Emergency Services
- M2M Applications/IoT
LTE 4G applications demand high-speed data uplink and downlink. High efficiency and high gain MIMO antennas are necessary to achieve the required signal to noise ratio and throughput required to solve these challenges. Taoglas also takes care to have high isolation between the two MIMO antennas to prevent self-interference. Low loss cables are used to keep efficiency high over long cable lengths. In contrast, smaller MIMO antennas with poorer quality thinner cables will have much-reduced efficiency and isolation, which would lead to a large drop in system throughput, increased number of drops, and may indeed not make a system connection at all.
| TECHNICAL SPECIFICATION | |
| Name | Value |
| Technology | External Antennas, Combination |
| IP Rating | IP67 |
| Impedance | 50 |
| Minimum Operating Temperature (℃) | -40 |
| Maximum Operating Temperature (℃) | 85 |
| Mounting Style | Wall |
| Termination Style | Connector |
| Antenna Connector Type | FAKRA |
| Length (mm) | 360 |
| Width (mm) | 160 |
| Height (mm) | 16.5 |
| Cable Type | TGC-200 |
| Connector Body Style | Straight |
| Polarity | RHCP, Linear |
| Frequency Range | 600MHz - 6000MHz |
| Connector Polarity | Normal |
| Cable Length (mm) | 1000 |
| VSWR | 02:01 |
| Weight (g) | 750 |
| RoHS | Yes |
| Gain (Max) | 2.46 |
