Taoglas
Taoglas CAMPTENNA Covert GPS, Wi-Fi & AM/FM 3-in-1 Headliner Adhesive Antenna
Product Code:
MA2330.A.ACT.002
Condition:
New
Weight:
0.15 KGS
Width:
8.40
(cm)
Height:
1.50
(cm)
Depth:
66.43
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
The MA2330 CAMPTENNA 3in1 Headliner adhesive antenna is a next-generation 3in1, embedded solution for vehicles. It’s made with robust ABS+PC housing. The antenna is approved for use on heavy-duty trucks and meets the strictest OEM heavy-duty truck standards. It supports the following bands: GNSS (GPS/GLONASS/GALILEO/BeiDou), Wi-Fi® (2.4/5.8GHz), and AM/FM/WB.
The antenna is first tier TS16949 heavy-duty truck approved and is an ideal choice for Automotive Telematic and heavy-duty plant applications.
The antenna comes with low-loss RG-174 coaxial pigtail cables as standard, terminating in FAKRA SMB code C for GNSS, FAKRA SMB code A for AM/FM/WB, and with FAKRA SMB code I for Wi-Fi®. The AM/FM/WB antenna is passive and utilizes a long metalized film to increase receive signal sensitivity. The antenna is manufactured in TS16949 automotive approved facilities.
| TECHNICAL SPECIFICATION | |
| Name | Value |
| Technology | External Antennas, Combination |
| IP Rating | IP21 |
| Impedance | 50 |
| Minimum Operating Temperature (℃) | -40 |
| Maximum Operating Temperature (℃) | 85 |
| Mounting Style | Adhesive |
| Termination Style | Connector |
| Antenna Connector Type | FAKRA |
| Length (mm) | 664.33 |
| Width (mm) | 83.99 |
| Height (mm) | 14.86 |
| Cable Type | RG-174 |
| Connector Body Style | Straight |
| Polarity | Linear |
| Frequency Range | 1575.42MHz - 2500MHz |
| Connector Polarity | Normal |
| Cable Length (mm) | 3000 |
| VSWR | 2:1 |
| Weight (g) | 145 |
| RoHS | Yes |
| Gain (Max) | 5 |
5 customers are viewing this product
Details
The MA2330 CAMPTENNA 3in1 Headliner adhesive antenna is a next-generation 3in1, embedded solution for vehicles. It’s made with robust ABS+PC housing. The antenna is approved for use on heavy-duty trucks and meets the strictest OEM heavy-duty truck standards. It supports the following bands: GNSS (GPS/GLONASS/GALILEO/BeiDou), Wi-Fi® (2.4/5.8GHz), and AM/FM/WB.
The antenna is first tier TS16949 heavy-duty truck approved and is an ideal choice for Automotive Telematic and heavy-duty plant applications.
The antenna comes with low-loss RG-174 coaxial pigtail cables as standard, terminating in FAKRA SMB code C for GNSS, FAKRA SMB code A for AM/FM/WB, and with FAKRA SMB code I for Wi-Fi®. The AM/FM/WB antenna is passive and utilizes a long metalized film to increase receive signal sensitivity. The antenna is manufactured in TS16949 automotive approved facilities.
| TECHNICAL SPECIFICATION | |
| Name | Value |
| Technology | External Antennas, Combination |
| IP Rating | IP21 |
| Impedance | 50 |
| Minimum Operating Temperature (℃) | -40 |
| Maximum Operating Temperature (℃) | 85 |
| Mounting Style | Adhesive |
| Termination Style | Connector |
| Antenna Connector Type | FAKRA |
| Length (mm) | 664.33 |
| Width (mm) | 83.99 |
| Height (mm) | 14.86 |
| Cable Type | RG-174 |
| Connector Body Style | Straight |
| Polarity | Linear |
| Frequency Range | 1575.42MHz - 2500MHz |
| Connector Polarity | Normal |
| Cable Length (mm) | 3000 |
| VSWR | 2:1 |
| Weight (g) | 145 |
| RoHS | Yes |
| Gain (Max) | 5 |
