Taoglas
Taoglas 2.4/5.8GHz Wi-Fi Dipole Terminal Mount Antenna
Product Code:
GW.40.2153
Condition:
New
Weight:
0.10 KGS
Width:
1.00
(cm)
Height:
10.90
(cm)
Depth:
1.00
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
The Taoglas GW.40 is a dual-band Wi-Fi® terminal mount antenna with a RP-SMA(M) connector. The dipole design makes it ideal for 2.4-2.5GHz/4.9-5.85GHz wireless applications such as Bluetooth® and Wireless LAN. At just 109mm in length, it has an omnidirectional radiation pattern. It has a gain value of 3.74dBi at 2.4GHz and 2.5dBi for 5GHz and ensures constant reception and transmission when integrated correctly.
Typical applications include:
- Routers/Gateways
- Industrial IoT
- Connected Enterprise
The antenna structure is designed with a robust TPU enclosure with a high quality finish. The antenna can be rotated 90 degrees on the base hinge for ease of placement. The GW.40 can be installed in MIMO configurations and orientated away from each other to improve isolation if necessary.
| TECHNICAL SPECIFICATION | |
| Name | Value |
| Technology | External Antennas, Wi-Fi®/Bluetooth® |
| Wi-Fi Bands | 2.4/5.8GHz |
| Impedance | 50 |
| Minimum Operating Temperature (℃) | -40 |
| Maximum Operating Temperature (℃) | 85 |
| Mounting Style | Terminal |
| Termination Style | Connector |
| Antenna Connector Type | RP-SMA |
| Length (mm) | 10 |
| Width (mm) | 10 |
| Height (mm) | 109 |
| Connector Body Style | Straight |
| Polarity | Linear |
| Frequency Range | 2.4/5.8GHz |
| Connector Polarity | Reverse |
| VSWR | <2 |
| Weight (g) | 10 |
| RoHS | Yes |
| Gain (Max) | 4.39 |
