SVP Aerospace
SVP Aerospace AVSC Omni Circular Antennas
Product Code:
AVSC
Condition:
New
Weight:
1.00 KGS
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
SVP Aerospace AVSC right hand circular polarized omni antennas are designed for applications requiring strength, particularly for vehicle roof applications and for fixed wing and rotary wing aircrafts.
These antennas serve as a complement to SVP slimline omni antenna range, similarly featuring highly efficient, wideband groundplane independent 2 tier arrays of balanced centre-fed collinear dipoles.
High performance with consistent gain and radiation pattern across their wide operating bands results from an unique conical dipole and double isolating.
| SPECIFICATIONS | |
| AVSC OMNI CIRCULAR ANTENNA | |
| Frequency | 2 – 2.5 GHz (AVSC-204) 4 – 6 GHz (AVSC-404) |
| Gain | 4 dBi |
| Elevation -3dB B/W | 50 degrees |
| Azimuth -3dB B/W | 360 degrees (omni, no ripple) |
| Polarization | RHCP |
| Return Loss | 14 dB Typical (1.7 to 1 VSWR) |
| Length | 381 mm (AVSC-204) 203.2 mm (AVSC-404) |
| Color | White |
| Connector | N female |
| Radome | Fibreglass |
| Mount | Through Hole Flange |
5 customers are viewing this product
Details
SVP Aerospace AVSC right hand circular polarized omni antennas are designed for applications requiring strength, particularly for vehicle roof applications and for fixed wing and rotary wing aircrafts.
These antennas serve as a complement to SVP slimline omni antenna range, similarly featuring highly efficient, wideband groundplane independent 2 tier arrays of balanced centre-fed collinear dipoles.
High performance with consistent gain and radiation pattern across their wide operating bands results from an unique conical dipole and double isolating.
| SPECIFICATIONS | |
| AVSC OMNI CIRCULAR ANTENNA | |
| Frequency | 2 – 2.5 GHz (AVSC-204) 4 – 6 GHz (AVSC-404) |
| Gain | 4 dBi |
| Elevation -3dB B/W | 50 degrees |
| Azimuth -3dB B/W | 360 degrees (omni, no ripple) |
| Polarization | RHCP |
| Return Loss | 14 dB Typical (1.7 to 1 VSWR) |
| Length | 381 mm (AVSC-204) 203.2 mm (AVSC-404) |
| Color | White |
| Connector | N female |
| Radome | Fibreglass |
| Mount | Through Hole Flange |
