PPC Belden
PPC Belden EX59XLHEPLUS RG59 Headend Connector, SignalTight (50 pcs)
Product Code:
EX59XLHEPLUS
Condition:
New
Weight:
1.00 KGS
$47.86
EX® Universal compression connector, SignalTight® continuity technology, extended body, headend cable
SignalTight® drop connectors achieve signal transmission approaching that of a fully-tightened connector, even if left loose. This innovative design protects against digital video artifacts, DOCSIS performance degradation, LTE interference, and upstream signal-to-noise issues. The result is an improved customer experience and the elimination of costly, unnecessary truck rolls and service calls to correct issues related to loose connectors.
Features & Benefits
- Knurled grip enhances ability to pre-tighten with fingers prior to wrench tightening
- Maintains ground continuity even when very loose
- Reduces QAM errors/packet loss
- Prevents service issues from loose connections
Package includes: 50 pieces of connectors.
| Electrical Specifications | |
| Bandwidth | 0 MHz to 3 GHz |
| Impedance | 75 Ohms (nominal) |
| Return Loss (Gated) | |
| 5 to 1,000 MHz | -30 dB Minimum |
| 1,000 to 2,000 MHz | -30 dB Minimum |
| 2,000 to 3,000 MHz | -20 dB Minimum |
| Insertion Loss | Less than 0.20 dB |
| 5 to 3,000 MHz | |
| Operating Voltage | 90 V (at 60 Hz continuous AC) |
| Operating Temperature | -40 °F to 140 °F (-40 °C to 60 °C) |
| Cable Retention | 45 lbs (20.41 kg) minimum |
5 customers are viewing this product
Details
EX® Universal compression connector, SignalTight® continuity technology, extended body, headend cable
SignalTight® drop connectors achieve signal transmission approaching that of a fully-tightened connector, even if left loose. This innovative design protects against digital video artifacts, DOCSIS performance degradation, LTE interference, and upstream signal-to-noise issues. The result is an improved customer experience and the elimination of costly, unnecessary truck rolls and service calls to correct issues related to loose connectors.
Features & Benefits
- Knurled grip enhances ability to pre-tighten with fingers prior to wrench tightening
- Maintains ground continuity even when very loose
- Reduces QAM errors/packet loss
- Prevents service issues from loose connections
Package includes: 50 pieces of connectors.
| Electrical Specifications | |
| Bandwidth | 0 MHz to 3 GHz |
| Impedance | 75 Ohms (nominal) |
| Return Loss (Gated) | |
| 5 to 1,000 MHz | -30 dB Minimum |
| 1,000 to 2,000 MHz | -30 dB Minimum |
| 2,000 to 3,000 MHz | -20 dB Minimum |
| Insertion Loss | Less than 0.20 dB |
| 5 to 3,000 MHz | |
| Operating Voltage | 90 V (at 60 Hz continuous AC) |
| Operating Temperature | -40 °F to 140 °F (-40 °C to 60 °C) |
| Cable Retention | 45 lbs (20.41 kg) minimum |
