PPC Belden
PPC Belden EX59PLUS SignalTight Premium EX Universal Connector Series 59, 6
Product Code:
EX59PLUS
Condition:
New
Weight:
1.00 KGS
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
Premium EX® Series SignalTight® connectors minimize the number of self-installs that become truck rolls. SignalTight technology means it achieves signal transmission approaching that of a fully-tightened connector, even if left loose. PPC’s EX connectors boast the largest dynamic range of any connector in the market, making it compatible with standard through quad shield cables. EX also doesn’t rely on an o-ring to seal the back end of the connector environmentally, it uses the dynamic range of the tough yet versatile plastic body to seal in the most effective way possible. The metal compression ring also allows us industry leading cable retention values through all cable sizes in the field.
Features & Benefits
- Unique 7/16 in nut profile allows hand tightening while discouraging wrench-tightening on CPEs
- Maintains ground continuity even when very loose
- Reduces QAM errors/packet loss
- Prevents service issues from loose connections
- Ideal for customer self-install kits
- Premium metal compression ring results in industry-leading cable retention values
- Compatible with standard through quad-shield cable
- Plastic body seals the back end of the connector from environmental factors
| Electrical Specifications | ||
| Bandwidth | 0 MHz to 3 GHz | |
| Impedance | 75 Ohms (nominal) | |
| Return Loss (Gated) | 5 to 1,000 MHz | -30 dB Minimum |
| 1,000 to 2000 MHz | -30 dB Minimum | |
| 2,000 to 3,000 MHz | -20 dB Minimum | |
| Insertion Loss | 5 to 3,000 MHz | Less than .20 dB |
| Operating Temperature | -40 °F to 140 °F (-40 °C to 60 °C) | |
| Cable Retention | 45 lbs (20.41 kg) minimum | |
5 customers are viewing this product
Details
Premium EX® Series SignalTight® connectors minimize the number of self-installs that become truck rolls. SignalTight technology means it achieves signal transmission approaching that of a fully-tightened connector, even if left loose. PPC’s EX connectors boast the largest dynamic range of any connector in the market, making it compatible with standard through quad shield cables. EX also doesn’t rely on an o-ring to seal the back end of the connector environmentally, it uses the dynamic range of the tough yet versatile plastic body to seal in the most effective way possible. The metal compression ring also allows us industry leading cable retention values through all cable sizes in the field.
Features & Benefits
- Unique 7/16 in nut profile allows hand tightening while discouraging wrench-tightening on CPEs
- Maintains ground continuity even when very loose
- Reduces QAM errors/packet loss
- Prevents service issues from loose connections
- Ideal for customer self-install kits
- Premium metal compression ring results in industry-leading cable retention values
- Compatible with standard through quad-shield cable
- Plastic body seals the back end of the connector from environmental factors
| Electrical Specifications | ||
| Bandwidth | 0 MHz to 3 GHz | |
| Impedance | 75 Ohms (nominal) | |
| Return Loss (Gated) | 5 to 1,000 MHz | -30 dB Minimum |
| 1,000 to 2000 MHz | -30 dB Minimum | |
| 2,000 to 3,000 MHz | -20 dB Minimum | |
| Insertion Loss | 5 to 3,000 MHz | Less than .20 dB |
| Operating Temperature | -40 °F to 140 °F (-40 °C to 60 °C) | |
| Cable Retention | 45 lbs (20.41 kg) minimum | |
