PPC Belden
PPC Belden EX320RAFMWS AquaTight EX Universal Compression Connector, right angle, 9/16’’ hex nut, series 320QR cable
Product Code:
EX320RAFMWS
Condition:
New
Weight:
1.00 KGS
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
AquaTight® EX® universal compression connector, right angle, 9/16’’ hex nut, series 320QR cable
EX320RAFMWS right angle hardline compression connectors install with the ease of a drop connector, simplifying and accelerating installation. These connectors are versatile, durable and designed to deliver signals with minimal loss and industry leading shielding effectiveness for series 320 QR cable.
| Technical Data | |
| Specification | Value |
| Bandwidth | 0 MHz to 1 GHz |
| Impedance | 75 Ohms (nominal) |
| Return Loss | Minimum -20 dB to 1 GHz |
| Insertion Loss | Less than .10 dB to 1.2 GHz |
| Operating Voltage | 90 V (at 60 Hz continunous AC) |
| Operating Temperature | -40° F to 140° F (-40° C to 60° C) |
| Cable Retention | 175 lbs (20.41 kg) minimum |
5 customers are viewing this product
Details
AquaTight® EX® universal compression connector, right angle, 9/16’’ hex nut, series 320QR cable
EX320RAFMWS right angle hardline compression connectors install with the ease of a drop connector, simplifying and accelerating installation. These connectors are versatile, durable and designed to deliver signals with minimal loss and industry leading shielding effectiveness for series 320 QR cable.
| Technical Data | |
| Specification | Value |
| Bandwidth | 0 MHz to 1 GHz |
| Impedance | 75 Ohms (nominal) |
| Return Loss | Minimum -20 dB to 1 GHz |
| Insertion Loss | Less than .10 dB to 1.2 GHz |
| Operating Voltage | 90 V (at 60 Hz continunous AC) |
| Operating Temperature | -40° F to 140° F (-40° C to 60° C) |
| Cable Retention | 175 lbs (20.41 kg) minimum |
