Persistent Systems
Persistent Systems RF-1150 High Power L-Band RF Module
Product Code:
RF-1150
Condition:
New
Weight:
0.13 KGS
Width:
9.70
(cm)
Height:
6.60
(cm)
Depth:
1.30
(cm)
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
Persistent’s High Power L-Band Interchangeable Frequency Module delivers increased output power and greater power efficiency to Military and Overseas customers.
This module also provides increased noise immunity in congested and contested RF environments.
| TECHNICAL SPECIFICATION | |
| Frequency Range | 1350 – 1390 MHz |
| RF Modulation | OFDM (64QAM, 16QAM, QPSK) |
| Antenna Chains | 3 Independent RF Chains |
| TX/RX Operating Modes | All MIMO modes from SISO to 3×3 |
| Channel Bandwidth | 5, 10, and 20 MHz Software Configurable |
| Peak TCP Throughput | 150 Mbps at 20 MHz Channel |
| MIMO Techniques | Maximal Ratio Combining Space-Time Block Coding Spatial Multiplexing" |
| Max. Aggregate Transmit Power | 10W (3.3W per RF Chain) |
| Antenna Ports | (3) SMP (50 Ohms) |
| TX Power Control | 35 to 16.5 dBm, 0.5 dB per step |
| Power Control Accuracy | +/- 2 dB |
| Frequency Accuracy | +/- 4 ppm, max. |
| Minimum Receiver Sensitivity | -95 dBm at 5 MHz bandwidth, QPSK |
| Max. RF Input | -20 dBm |
| Max. RF Input without Damage | +10 dBm |
| Max. Peak Power Consumption, TX | TBD |
| Power Consumption, RX | TBD |
| Operating Temperature | -40°C to +85°C |
| ESD Protection | +/- 8KV Contact discharge, per IEC 6100-4-2 |
| Dimensions | 3.8 x 2.6 x 0.5 in. 9.7 x 6.6 x 1.3 cm |
| Weight | 4.3 oz. 122 g |
