PEPLINK
Peplink MAX-BR1-MINI-M2M-LTE-US-T-PRM MAX BR1 Mini M2M
Product Code:
MAX-BR1-MINI-M2M-LTE-US-T-PRM
Condition:
New
Availability:
YES
Weight:
0.82 KGS
Width:
35.56
(cm)
Height:
10.16
(cm)
Depth:
27.94
(cm)
$399.00
Peplink MAX-BR1-MINI-M2M CAT 4 LTE Modem,1-Year PrimeCare
Secure your network with enhanced reliability even in industrial environments. Connect and easily manage your industrial equipment and IoT devices with this palm-sized device. The MAX-BR1-MINI-M2M is built for maintaining a stable connection while withstanding tough environments, such as factories, power plants and outdoor deployments. Featuring an RS-232/RS-485 serial port, the BR1 MINI M2M is your best solution to bring connectivity to versatile industrial equipment and IoT devices. The advanced InTouch technology allows for secure remote monitoring and management of your linked industrial device through a single cloud platform.
Power the device via PoE or Micro-Fit connector, allowing for flexible installations no matter your requirements.
With SpeedFusion Connect 5G/LTE, you can access on-demand data plans and only pay for what you need. SpeedFusion Connect 5G/LTE is an all-in-one solution offering access to not only SpeedFusion Connect Protect but also LTE data.
This Peplink product comes with a one-year limited warranty. The first year of PrimeCare is included in the purchase of this PrimeCare device, with the ability to continue afterwards via paid subscription. You can upgrade to PrimeCare+ for additional benefits. Compare the Peplink Care Plans and select one that fits you and your deployment needs.
Key Features
- Dedicated for M2M Deployments
- 1x Embedded 4G LTE Modem (North America/ CAT-4)
- 1x Ethernet LAN
- 1x Optional Ethernet WAN
- 1x 9-pin serial connector
- Optional WAN Failover
- Dual-Band Wi-Fi 5, 2x2 MIMO
- GPS/Fleet Tracking
- Full antenna set
- 300 Mbps Throughput
- Nano-SIM (4FF)
- Cellular Data Rate (Downlink/Uplink) 150 Mbps / 50 Mbps
- InControl2
- Carrier Certifications: AT&T, T-Mobile, Verizon, FirstNet
Contact Us About Data Plans
Enable your MAX-BR1-MINI-M2M with a cost-effective data plan to ensure your router is ready to deploy. Call Orbital Connect Sales team for information.
High-Performance Antenna Options
The Peplink MAX-BR1-MINI-M2M includes two LTE antennas, two WiFi antennas, and one GPS antenna. For mobile and industrial applications, consider other High-Performance Antennas or speak with a our specialists.
In the Box
- MAX BR1 MINI M2M
- 2x LTE Antennas (ACW-235)
- 2x Wi-Fi Dual Band Antennas (ACW-342)
- 1x GPS Active Antenna (ACW-232)
- 1x 12V 2A 4 Pin Power Supply (ACW-632)
| Category | Cellular Router |
| SIM Holder | 2 SIM slots (4FF form factor) |
| Antenna | 2 LTE, 2 WiFi, 1 GPS |
| Cloud Protocols | InControl Cloud Management |
| Wi-Fi Frequencies | Dual (2.4GHz + 5GHz) 2x2 MIMO |
| Power Consumption | 13W (nominal), 18W (max.) |
| Input Voltage | 10-30V DC |
| Dimensions | 5.1 x 4.2 x 1.4 in (129.5 x 107 x 35 mm) |
| Weight | 1 pound (455 grams) |
| Antenna Connection | 3x SMA (cellular & GPS), 2x RP-SMA (Wi-Fi) |
| Operating Temperature | -40° to 149°F (-40° to 65°C) |
| Humidity | 15 to 95% non-condensing |
| Certifications | FCC, IC |
| Warranty | 1-Year Limited Warranty |
5 customers are viewing this product
Details
Peplink MAX-BR1-MINI-M2M CAT 4 LTE Modem,1-Year PrimeCare
Secure your network with enhanced reliability even in industrial environments. Connect and easily manage your industrial equipment and IoT devices with this palm-sized device. The MAX-BR1-MINI-M2M is built for maintaining a stable connection while withstanding tough environments, such as factories, power plants and outdoor deployments. Featuring an RS-232/RS-485 serial port, the BR1 MINI M2M is your best solution to bring connectivity to versatile industrial equipment and IoT devices. The advanced InTouch technology allows for secure remote monitoring and management of your linked industrial device through a single cloud platform.
Power the device via PoE or Micro-Fit connector, allowing for flexible installations no matter your requirements.
With SpeedFusion Connect 5G/LTE, you can access on-demand data plans and only pay for what you need. SpeedFusion Connect 5G/LTE is an all-in-one solution offering access to not only SpeedFusion Connect Protect but also LTE data.
This Peplink product comes with a one-year limited warranty. The first year of PrimeCare is included in the purchase of this PrimeCare device, with the ability to continue afterwards via paid subscription. You can upgrade to PrimeCare+ for additional benefits. Compare the Peplink Care Plans and select one that fits you and your deployment needs.
Key Features
- Dedicated for M2M Deployments
- 1x Embedded 4G LTE Modem (North America/ CAT-4)
- 1x Ethernet LAN
- 1x Optional Ethernet WAN
- 1x 9-pin serial connector
- Optional WAN Failover
- Dual-Band Wi-Fi 5, 2x2 MIMO
- GPS/Fleet Tracking
- Full antenna set
- 300 Mbps Throughput
- Nano-SIM (4FF)
- Cellular Data Rate (Downlink/Uplink) 150 Mbps / 50 Mbps
- InControl2
- Carrier Certifications: AT&T, T-Mobile, Verizon, FirstNet
Contact Us About Data Plans
Enable your MAX-BR1-MINI-M2M with a cost-effective data plan to ensure your router is ready to deploy. Call Orbital Connect Sales team for information.
High-Performance Antenna Options
The Peplink MAX-BR1-MINI-M2M includes two LTE antennas, two WiFi antennas, and one GPS antenna. For mobile and industrial applications, consider other High-Performance Antennas or speak with a our specialists.
In the Box
- MAX BR1 MINI M2M
- 2x LTE Antennas (ACW-235)
- 2x Wi-Fi Dual Band Antennas (ACW-342)
- 1x GPS Active Antenna (ACW-232)
- 1x 12V 2A 4 Pin Power Supply (ACW-632)
| Category | Cellular Router |
| SIM Holder | 2 SIM slots (4FF form factor) |
| Antenna | 2 LTE, 2 WiFi, 1 GPS |
| Cloud Protocols | InControl Cloud Management |
| Wi-Fi Frequencies | Dual (2.4GHz + 5GHz) 2x2 MIMO |
| Power Consumption | 13W (nominal), 18W (max.) |
| Input Voltage | 10-30V DC |
| Dimensions | 5.1 x 4.2 x 1.4 in (129.5 x 107 x 35 mm) |
| Weight | 1 pound (455 grams) |
| Antenna Connection | 3x SMA (cellular & GPS), 2x RP-SMA (Wi-Fi) |
| Operating Temperature | -40° to 149°F (-40° to 65°C) |
| Humidity | 15 to 95% non-condensing |
| Certifications | FCC, IC |
| Warranty | 1-Year Limited Warranty |
Download
| Download Name | |
| MAX BR1 Mini M2M Datasheet | |
