Norsat International Inc.
Norsat WOMD045P WAYFARER 0.45m Ku/Ka Dual Frequency Parabolic Antenna
Product Code:
WOMD045P
Condition:
New
Availability:
10 - 12 Weeks
Weight:
40.00 KGS
$159,500.00
| KEY SPECIFICATIONS | |
| Antenna Category | On the Move |
| Band | Ku-Band/Ka-Band |
| Of Onboard Los | Dual-Band |
| ANTENNA SPECIFICATIONS | |
| Antenna Aperture | 0.45m |
| Antenna Type | King focus loop local |
| Auto Acquisition Time | ≤ 2min |
| Azimuth Acceleration | ≥ 200°/s² |
| Azimuth Velocity | ≤ 60°/s |
| Blockage Recovery Time | ≤ 5s (Blockage 20 min) |
| Cross Polarization Isolation | ≥ 30 dB |
| Elevation Acceleration | ≥ 200°/s² |
| Elevation Veolcity | ≤ 60°/s |
| Motion Range AZ | 360° infinity |
| Motion Range EL | 10° - 90° |
| Motion Range POL | ± 95° (Ku-Band) |
| Polarization | Ku-Band: Linear/Ka-Band: Circular |
| Polarization Velocity | ≤40°/s |
| Sidelobe | azimuth: ≤ -13dB, elevation: ≤ -12dB |
| RF SPECIFICATIONS | |
| Port Isolation Rx-Tx | 85 dB |
| Port Isolation Tx-Rx | 85 dB |
| Power Capacity | 100 W |
| Rx Frequency | Ku-Band: 12.25 - 12.75 GHz; Ka-Band: 19.60 - 21.20 GHz |
| Rx Gain | Ku-Band: 32.5+20lg(f/12.50)dBi; Ka-Band: 36.4+20lg(f/20.40)dBi |
| Rx Interface | Ku-Band: WR75; Ka-Band: WR42 |
| Rx VSWR | ≤ 1.5 : 1 |
| Tx Frequency | Ku-Band: 14.00 - 14.50 GHz; Ka-Band: 29.40 - 31.00 GHz |
| Tx Gain | Ku-Band: 32.8+20lg(f/14.25)dBi; Ka-Band: 38.3+20lg(f/30.20)dBi |
| Tx Interface | Ku-Band: WR75; Ka-Band: WR28 |
| Tx VSWR | ≤ 1.5 : 1 |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | Static 100w, dynamic 200w (without power amplifier) |
| Power Supply | 220 VAC |
| INTERFACE SPECIFICATIONS | |
| Positioning Mode | GPS+Beidou |
| ENVIRONMENTAL SPECIFICATIONS | |
| Humidity | 95% (20°C) |
| IP Rating | IP65 |
| Temperature Operational | -40°C to +60°C |
| Temperature Storage | -50°C to +70°C |
| Windspeed Operational | ≤ 21m/s |
| Windspeed Survival | ≤ 35m/s |
| PHYSICAL SPECIFICATIONS | |
| Color | White |
| Default Cable (Included) | Communication cables, Power supply cables, RF cables, Electrical power cables |
| Default Cable Length | 10m |
| Product Weight | ≤ 40 kg (excluding power amplifier, LNB, packaging and accessories) |
| RMS | ≤ 0.5 dB (R.M.S) |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Ex Works | Hong Kong |
| Harmonized System Code | 8529109090 |
| Warranty | 1 year |
