Norsat International Inc.
Norsat WOMD045H Hybrid Steering Ku/Ka Dual Band Phased Array Antenna
Product Code:
WOMD045H
Condition:
New
Availability:
10 - 12 Weeks
Weight:
75.00 KGS
Width:
116.00
(cm)
Height:
12.00
(cm)
Depth:
118.00
(cm)
$173,600.00
WOMD045H is a model which can work simultaneously on both Ku and Ka bands. It provides user with the maximized flexibility and reliability when facing the most challenging situation. It features compact and ruggedized design, low power consumption, and great easiness for installation, ensuring seamless satellite network experience while on the move.
| KEY SPECIFICATIONS | |
| Band | Ku and Ka Simultaneously |
| ANTENNA SPECIFICATIONS | |
| Antenna Type | Hybrid Steering Dual-band Phased Array Antenna |
| Axis Ratio | ≤ 1.0 dB |
| Azimuth Angle | 0° - 360° |
| Elevation Angle | 25° - 85° |
| Locking Time | ≤120 s |
| Polarization | Linear & LHCP/RHCP automatic |
| Tracking Accuracy | ≤0.2° RMS |
| RF SPECIFICATIONS | |
| EIRP | ≥47 dBW @ 14.5 GHz/29.5 GHz |
| G/T | ≥10dB/K@12.5GHz/20GHz |
| Gain | Ku-Band: 34 dB; Ka-Band: 33 dB |
| Rx Frequency | 10.70 - 12.75 GHz (Ku-Band); 13.75 - 14.00 GHz (Ka-Band) |
| Tx Frequency | 17.70 - 21.20 GHz (Ku-Band); 27.50 - 31.00 GHz (Ka-Band) |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | ≤600W |
| Power Supply | 220V AC/24V DC |
| INTERFACE SPECIFICATIONS | |
| ACU | Internal ACU |
| Port | Composite aviation connector for IF, power and control |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP 65 |
| Temperature Operational | -40℃ - 60℃ |
| PHYSICAL SPECIFICATIONS | |
| Color | White |
| Product Height | 120 mm |
| Product Length | 1180 mm |
| Product Weight | 75 kg |
| Product Width | 1160 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0 Kg |
| Aluminium Total Value | $ 0 |
| Country Of Origin | Made in China |
| Ex Works | Hong Kong |
| Harmonized System Code | 8529109090 |
| Unit Package Dimensions | 1300 x 1200 x 400 mm |
| Unit Package Height | 400 mm |
| Unit Package Length | 1300 mm |
| Unit Package Weight | 100 kg |
| Unit Package Width | 1200 mm |
| Warranty | 1 year |
