Norsat International Inc.
Norsat WFA370CF WAYFARER 3.7m C-Band Box Automatically Transportable Antenna - Feed Forward
Product Code:
WFA370CF
Condition:
New
Availability:
10 - 12 Weeks
Weight:
615.00 KGS
Width:
420.00
(cm)
Height:
450.00
(cm)
Depth:
550.00
(cm)
$467,500.00
| KEY SPECIFICATIONS | |
| Antenna Aperture | 3.7m |
| Antenna Category | Auto Flyaway |
| Band | C-Band |
| Number Of Onboard Los | Single-Band |
| ANTENNA SPECIFICATIONS | |
| Antenna Type | Feed Forward |
| Azimuth Angle | EL＞36° AZ: ±180°；EL≤36° AZ: ±60° |
| Azimuth Velocity | 0.1°/s～3°/s |
| Blockage Recovery Time | ≤1min |
| Cross Polarization Isolation | ≥30 dB |
| Elevation Angle | 0° - 90° |
| Elevation Veolcity | 0.1°/s～0.05°/s |
| Initial Auto Acquisition Time | ≤3min |
| Polarization | Linear |
| Polarization Range | ±90° |
| Polarization Velocity | 0.1°/s～3°/s |
| Sidelobe | ≤-14dB |
| RF SPECIFICATIONS | |
| Port Isolation Rx-Tx | ≥85dB |
| Port Isolation Tx-Rx | ≥40dB |
| Power Capacity | ≤500W |
| Rx Frequency | 3.40 - 4.20 GHz |
| Rx Gain | 40.5+20lg(f/3.8) |
| Rx Interface | WR229 |
| Rx VSWR | ≤ 1.50 : 1 |
| Tx Frequency | 5.85 - 6.725 GHz |
| Tx Gain | 44.9+20lg(f/6.3) |
| Tx Interface | WR137 |
| Tx VSWR | ≤ 1.50 : 1 |
| ELECTRICAL SPECIFICATIONS | |
| Power Supply | 220VAC±10，50Hz±2Hz; ≤600W（No power amplifier） |
| ENVIRONMENTAL SPECIFICATIONS | |
| Humidity | 95%（20°C） |
| IP Rating | IP65 |
| Temperature Operational | -40°C to +60°C |
| Temperature Storage | -50°C to +70°C |
| Windspeed Operational | 13m/s |
| Windspeed Survival | 20m/s |
| PHYSICAL SPECIFICATIONS | |
| Color | White |
| Default Cable (Included) | Power supply, network cable, RF Cable |
| Default Cable Length | 10 m |
| Number Of Cases | 6 |
| Packed By | wood crate and aluminium shipping case |
| Product Height | 4500 mm |
| Product Length | 5500 mm |
| Product Weight | 615 kg |
| Product Width | 4200 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0 Kg |
| Aluminium Total Value | $ 0 |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Ex Works | Hong Kong |
| Harmonized System Code | 8529109090 |
| Package Height Case 1 | 650 mm |
| Package Height Case 2 | 650 mm |
| Package Height Case 3 | 650 mm |
| Package Height Case 4 | 650 mm |
| Package Height Case 5 | 650 mm |
| Package Height Case 6 | 650 mm |
| Package Length Case 1 | 1450 mm |
| Package Length Case 2 | 1450 mm |
| Package Length Case 3 | 1450 mm |
| Package Length Case 4 | 1450 mm |
| Package Length Case 5 | 1450 mm |
| Package Length Case 6 | 1450 mm |
| Package Weight Case 1 | 100 kg |
| Package Weight Case 2 | 115 kg |
| Package Weight Case 3 | 115 kg |
| Package Weight Case 4 | 130 kg |
| Package Weight Case 5 | 130 kg |
| Package Weight Case 6 | < 90 kg |
| Package Width Case 1 | 1250 mm |
| Package Width Case 2 | 1250 mm |
| Package Width Case 3 | 1250 mm |
| Package Width Case 4 | 1250 mm |
| Package Width Case 5 | 1250 mm |
| Package Width Case 6 | 1250 mm |
| Unit Package Dimensions | 1450*1250*650(mm) |
| Unit Package Weight | 680 kg |
| Warranty | 1 year |
