Norsat International Inc.
Norsat WFA060XF WAYFARER 0.6m X-Band Auto Flyaway Antenna - Feed Forward
Product Code:
WFA060XF
Condition:
New
Availability:
10 - 12 Weeks
Weight:
18.00 KGS
$49,500.00
| KEY SPECIFICATIONS | |
| Antenna Aperture | 0.6m |
| Antenna Category | Auto Flyaway |
| Band | X-Band |
| Number Of Onboard Los | Single-Band |
| ANTENNA SPECIFICATIONS | |
| Antenna Type | Feed Forward |
| Axis Ratio | ≤ 1.5dB |
| Azimuth Angle | ± 180° |
| Elevation Angle | 10° - 90° |
| Polarization | Circular |
| Sidelobe | First sidelobe ≤ -14 dB |
| RF SPECIFICATIONS | |
| Port Isolation Rx-Tx | 85 dB |
| Port Isolation Tx-Rx | 85 dB |
| Power Capacity | 100 W |
| Rx Frequency | 7.25 - 7.75 GHz |
| Rx Gain | ≥ 30.44dBi+20lg(f/7.25GHz)dBi |
| Rx Interface | WR112 |
| Rx VSWR | ≤ 1.5：1 |
| Tx Frequency | 7.90 - 8.40 GHz |
| Tx Gain | ≥ 31.7dBi+20lg(f/7.9GHz)dBi |
| Tx Interface | WR112 |
| Tx VSWR | ≤ 1.5：1 |
| INTERFACE SPECIFICATIONS | |
| Positioning Mode | Beacon/DVB carrier |
| ENVIRONMENTAL SPECIFICATIONS | |
| Humidity | 95% (20℃) |
| IP Rating | IP 65 |
| Temperature Operational | -35°C to +60°C |
| Temperature Storage | -50 °C to +70°C |
| Windspeed Operational | ≤ 11m/s |
| Windspeed Survival | ≤ 18m/s |
| PHYSICAL SPECIFICATIONS | |
| Color | White |
| Default Cable (Included) | Power Supply and RF cable |
| Default Cable Length | 10m |
| Product Weight | ≤ 18 kg (excluding BUC, LNB, packaging and accessories) |
| RMS | 0.3dB |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0 Kg |
| Aluminium Total Value | $ 0 |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Ex Works | Hong Kong |
| Harmonized System Code | 8517710000 |
| Warranty | 1 year |
