Norsat International Inc.
Norsat WFA-100222 WAYFARER 1.3m Ku/KA-Band Auto Flyaway Antenna with Exchangeable feed
Product Code:
WFA-100222
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.00 KGS
$0.00
| KEY SPECIFICATIONS | |
| Antenna Aperture | 1.3m |
| Antenna Category | Auto Flyaway |
| Band | KA-Band / Ku-Band |
| Tracking Mode | Beacon/DVB carrier |
| ANTENNA SPECIFICATIONS | |
| Auto Acquisition Time | ≤ 3 min |
| Axial Ratio | KA-Band: 1.5 dB max (On Axis) Ku-band: N/A |
| Cross Polarization Isolation | KA-Band: N/A Ku-Band: 35 dB min (On Axis) |
| Feed Type | Splash plate feed |
| Motion Range AZ | ± 200° |
| Motion Range EL | 0° - 90° |
| Motion Range POL | Ku-Band: ± 90° |
| Polarization | KA-Band: Circular Ku-Band: Linear |
| Power Supply | 220V AC/50Hz |
| Sidelobe | First sidelobe ≤ -14 dB |
| Speed Of Movement | AZ: 0.1 to 3°/s EL: 0.1 to 3°/s Polarization: 0.1 to 6°/s |
| RF SPECIFICATIONS | |
| Feed Interface | KU-Band: RX: WR75, TX: WR75 KA-Band: RX: WR42, TX: WR28 |
| Noise Temperature Typ | KU-Band: 80k max (El 10°, no wind, sunny weather) KA-Band: 170k max (El 10°, no wind, sunny weather) |
| Port Isolation Tx-Rx | 85 dB min |
| Rx Frequency | KA-Band: 17.7 - 21.2 GHz Ku-Band: 10.70 - 12.75 GHz |
| Rx Gain | KA-Band: 46.1+20lg(f/19.6) dBi Ku-Band: 42.1+20lg(f/12.25) dBi |
| Tracking Accuracy | ≤0.3dB (R.M.S) |
| Tx Frequency | KA-Band: 27.5 - 31.0 GHz Ku-Band: 13.75 - 14.50 GHz |
| Tx Gain | KA-Band: 49.6+20lg(f/29.4) dBi Ku-Band: 43.2+20lg(f/14.0) dBi |
| VSWR | KU-Band: 1.5 : 1 max KA-Band: 1.5 : 1 max |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | ≤200 watts |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rate | IP65 |
| Relative Humidity | 0-95% (20 °C) |
| Temperature Operational | -25℃ to +55℃ |
| Temperature Survival | -50℃ to +70℃ |
| Windspeed Operational | ≤ 11m/s |
| Windspeed Survival | ≤ 20m/s |
| PHYSICAL SPECIFICATIONS | |
| Number Of Cases | 2 Cases, 32kg max each (excludes BUC, LNB, packaging and accessories) |
| Reflector Construction | Carbon Fiber |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Ex Works | Shenzhen |
| Harmonized System Code | 8517700000 |
| Warranty | 1 year |
5 customers are viewing this product
Details
| KEY SPECIFICATIONS | |
| Antenna Aperture | 1.3m |
| Antenna Category | Auto Flyaway |
| Band | KA-Band / Ku-Band |
| Tracking Mode | Beacon/DVB carrier |
| ANTENNA SPECIFICATIONS | |
| Auto Acquisition Time | ≤ 3 min |
| Axial Ratio | KA-Band: 1.5 dB max (On Axis) Ku-band: N/A |
| Cross Polarization Isolation | KA-Band: N/A Ku-Band: 35 dB min (On Axis) |
| Feed Type | Splash plate feed |
| Motion Range AZ | ± 200° |
| Motion Range EL | 0° - 90° |
| Motion Range POL | Ku-Band: ± 90° |
| Polarization | KA-Band: Circular Ku-Band: Linear |
| Power Supply | 220V AC/50Hz |
| Sidelobe | First sidelobe ≤ -14 dB |
| Speed Of Movement | AZ: 0.1 to 3°/s EL: 0.1 to 3°/s Polarization: 0.1 to 6°/s |
| RF SPECIFICATIONS | |
| Feed Interface | KU-Band: RX: WR75, TX: WR75 KA-Band: RX: WR42, TX: WR28 |
| Noise Temperature Typ | KU-Band: 80k max (El 10°, no wind, sunny weather) KA-Band: 170k max (El 10°, no wind, sunny weather) |
| Port Isolation Tx-Rx | 85 dB min |
| Rx Frequency | KA-Band: 17.7 - 21.2 GHz Ku-Band: 10.70 - 12.75 GHz |
| Rx Gain | KA-Band: 46.1+20lg(f/19.6) dBi Ku-Band: 42.1+20lg(f/12.25) dBi |
| Tracking Accuracy | ≤0.3dB (R.M.S) |
| Tx Frequency | KA-Band: 27.5 - 31.0 GHz Ku-Band: 13.75 - 14.50 GHz |
| Tx Gain | KA-Band: 49.6+20lg(f/29.4) dBi Ku-Band: 43.2+20lg(f/14.0) dBi |
| VSWR | KU-Band: 1.5 : 1 max KA-Band: 1.5 : 1 max |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | ≤200 watts |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rate | IP65 |
| Relative Humidity | 0-95% (20 °C) |
| Temperature Operational | -25℃ to +55℃ |
| Temperature Survival | -50℃ to +70℃ |
| Windspeed Operational | ≤ 11m/s |
| Windspeed Survival | ≤ 20m/s |
| PHYSICAL SPECIFICATIONS | |
| Number Of Cases | 2 Cases, 32kg max each (excludes BUC, LNB, packaging and accessories) |
| Reflector Construction | Carbon Fiber |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Ex Works | Shenzhen |
| Harmonized System Code | 8517700000 |
| Warranty | 1 year |
