Norsat International Inc.
Norsat ULC-1-75-CL-6 Universal LNB Controller 6-Band
Product Code:
ULC-1-75-CL-6
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.85 KGS
Width:
12.00
(cm)
Height:
3.00
(cm)
Depth:
13.00
(cm)
$4,200.00
| KEY SPECIFICATIONS | |
| Control Signal | Control Interface Cable & Line Length Compensation with Switch |
| Reference Signal | 10MHz internal |
| Tone Amplitude | 0.55 ~ 0.9 vpp |
| Tone Frequency | 20 ~ 24 kHz |
| ELECTRICAL SPECIFICATIONS | |
| Current Consumption | 1100 mA max. |
| Output Current | 500 mA max. |
| Power Requirements | +23 to +25 V DC |
| INTERFACE SPECIFICATIONS | |
| Connector | F-Connector |
| Control Interface | Control Interface Cable & Line Length Compensation with Switch |
| LLC Line Length Compensation | +1 VDC (Switch) |
| RF Input Connector | 75 Ohm F Connector |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP 65 |
| Temperature Operational | -40°C to +60°C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 30 mm |
| Product Length | 130 mm |
| Product Weight | 0.85 kg |
| Product Width | 120 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.25 kg |
| Aluminium COO | KR |
| Aluminium Total Value | $ 0.625 |
| Country Of Origin | Made in the Republic of Korea |
| ECCN Number | EAR99 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 8517690000 |
| Warranty | 3 years |
5 customers are viewing this product
Details
| KEY SPECIFICATIONS | |
| Control Signal | Control Interface Cable & Line Length Compensation with Switch |
| Reference Signal | 10MHz internal |
| Tone Amplitude | 0.55 ~ 0.9 vpp |
| Tone Frequency | 20 ~ 24 kHz |
| ELECTRICAL SPECIFICATIONS | |
| Current Consumption | 1100 mA max. |
| Output Current | 500 mA max. |
| Power Requirements | +23 to +25 V DC |
| INTERFACE SPECIFICATIONS | |
| Connector | F-Connector |
| Control Interface | Control Interface Cable & Line Length Compensation with Switch |
| LLC Line Length Compensation | +1 VDC (Switch) |
| RF Input Connector | 75 Ohm F Connector |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP 65 |
| Temperature Operational | -40°C to +60°C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 30 mm |
| Product Length | 130 mm |
| Product Weight | 0.85 kg |
| Product Width | 120 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.25 kg |
| Aluminium COO | KR |
| Aluminium Total Value | $ 0.625 |
| Country Of Origin | Made in the Republic of Korea |
| ECCN Number | EAR99 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 8517690000 |
| Warranty | 3 years |
Download
| Download Name | |
| Norsat 6-Band Universal LNB Controller Data Sheet | |
