Norsat International Inc.
Norsat PS480-AT1-CN 480W ATOM Power Supply
Product Code:
PS480-AT1-CN
Weight:
2.80 KGS
Width:
26.20
(cm)
Height:
4.38
(cm)
Depth:
26.20
(cm)
$1,500.00
|
KEY SPECIFICATIONS |
|
| color | Silver |
| input frequency band 1 | 47 - 63 Hz |
| output power rated | 480W |
| Product Revision | B |
|
ELECTRICAL SPECIFICATIONS |
|
| input voltage | 90 - 305 VAC |
| output voltage | +48 V |
| output voltage accuracy | +/- 5% of output voltage |
| output voltage ripple noise | 1.0V Peak-to-Peak |
| rated current | 10:00 AM |
|
INTERFACE SPECIFICATIONS |
|
| AC input cable | 5m (16.5 ft), North America (NEMA 5/15) |
| DC output cable | 2m (6 ft) Socket reference: PT06E-12-4S-476 |
|
ENVIRONMENTAL SPECIFICATIONS |
|
| temperature operational | -35 to +70°C |
| temperature storage | -40 to +85˚C |
|
PHYSICAL SPECIFICATIONS |
|
| cooling | Passive / Fanless |
| product dimensions (LxWxH) | 262 x 125 x 43.8 mm |
| product weight | 2.8 kg |
5 customers are viewing this product
Details
|
KEY SPECIFICATIONS |
|
| color | Silver |
| input frequency band 1 | 47 - 63 Hz |
| output power rated | 480W |
| Product Revision | B |
|
ELECTRICAL SPECIFICATIONS |
|
| input voltage | 90 - 305 VAC |
| output voltage | +48 V |
| output voltage accuracy | +/- 5% of output voltage |
| output voltage ripple noise | 1.0V Peak-to-Peak |
| rated current | 10:00 AM |
|
INTERFACE SPECIFICATIONS |
|
| AC input cable | 5m (16.5 ft), North America (NEMA 5/15) |
| DC output cable | 2m (6 ft) Socket reference: PT06E-12-4S-476 |
|
ENVIRONMENTAL SPECIFICATIONS |
|
| temperature operational | -35 to +70°C |
| temperature storage | -40 to +85˚C |
|
PHYSICAL SPECIFICATIONS |
|
| cooling | Passive / Fanless |
| product dimensions (LxWxH) | 262 x 125 x 43.8 mm |
| product weight | 2.8 kg |
Download
| Download Name | |
| 480W ATOM Power Supply | |
