Norsat International Inc.
Norsat OPT162BR OPTIVIA 30x EO + 3000m Laser Rangefinder Gimbal Camera
$37,600.00
Zoom the image with the mouse
Norsat International Inc.
Norsat OPT072AR OPTIVIA Miniaturized EO/IR Fixed-Focus Camera: 1200m LRF + Dual Video Streams
Product Code:
OPT072AR
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.22 KGS
Width:
7.20
(cm)
Height:
10.50
(cm)
Depth:
7.20
(cm)
$14,600.00
| KEY SPECIFICATIONS | |
| Recording Time | ≥60 min ≥ Small drone flight time |
| Stabilization Accuracy Horizontal Jitter Angle | ±0.03° |
| Stabilization Accuracy Pitch Jitter Angle | ±0.02° |
| Stabilization Accuracy Roll Jitter Angle | ±0.02° |
| Standard Preinstalled Components | 4K Zoom Camera; 1080P Zoom Camera; Laser Rangefinder |
| RF SPECIFICATIONS | |
| Laser Rangefinder Accuracy | ±1m |
| Laser Rangefinder Operating Wavelength | 905nm |
| Laser Rangefinder Ranging Range | 5 - 1200m |
| Visible Light Fov | 4K: 25 mm lens FOV: 10.5° x 7.8°; 1080P: 6 mm lens FOV: 60° x 43° |
| Visible Light Resolution | 1080P@30fps /4K@30fps |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | Dynamic: 6W |
| Power Supply | DC 12V - 26.2V, the instantaneous voltage of the power supply must not exceed 27V |
| INTERFACE SPECIFICATIONS | |
| Control Method | IP, UART,SBUS (PWM optional) |
| External Interface Communication Interface | TTL |
| External Interface Video Interface | Local TF Card Storage, H264 4K/1080P, Video Streams |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -10°C to +45°C (20% - 80%) |
| Temperature Storage | -20°C to +60°C (20% to 95% RH) |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 105 mm |
| Product Length | 72 mm |
| Product Weight | 0.22 kg |
| Product Width | 72 mm |
| Rotation Range Azimuth | -140° to +140° |
| Rotation Range Elevation | -30° to +100° |
| Volume | Φ: 72 × H: 105 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Harmonized System Code | 8525893900 |
| Unit Package Dimensions | 280 x 230 x 280 mm |
| Unit Package Weight | 5 kg |
| Warranty | 1 |
5 customers are viewing this product
Details
| KEY SPECIFICATIONS | |
| Recording Time | ≥60 min ≥ Small drone flight time |
| Stabilization Accuracy Horizontal Jitter Angle | ±0.03° |
| Stabilization Accuracy Pitch Jitter Angle | ±0.02° |
| Stabilization Accuracy Roll Jitter Angle | ±0.02° |
| Standard Preinstalled Components | 4K Zoom Camera; 1080P Zoom Camera; Laser Rangefinder |
| RF SPECIFICATIONS | |
| Laser Rangefinder Accuracy | ±1m |
| Laser Rangefinder Operating Wavelength | 905nm |
| Laser Rangefinder Ranging Range | 5 - 1200m |
| Visible Light Fov | 4K: 25 mm lens FOV: 10.5° x 7.8°; 1080P: 6 mm lens FOV: 60° x 43° |
| Visible Light Resolution | 1080P@30fps /4K@30fps |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | Dynamic: 6W |
| Power Supply | DC 12V - 26.2V, the instantaneous voltage of the power supply must not exceed 27V |
| INTERFACE SPECIFICATIONS | |
| Control Method | IP, UART,SBUS (PWM optional) |
| External Interface Communication Interface | TTL |
| External Interface Video Interface | Local TF Card Storage, H264 4K/1080P, Video Streams |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -10°C to +45°C (20% - 80%) |
| Temperature Storage | -20°C to +60°C (20% to 95% RH) |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 105 mm |
| Product Length | 72 mm |
| Product Weight | 0.22 kg |
| Product Width | 72 mm |
| Rotation Range Azimuth | -140° to +140° |
| Rotation Range Elevation | -30° to +100° |
| Volume | Φ: 72 × H: 105 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Harmonized System Code | 8525893900 |
| Unit Package Dimensions | 280 x 230 x 280 mm |
| Unit Package Weight | 5 kg |
| Warranty | 1 |
