Norsat International Inc.
Norsat OPT076DX OPTIVIA Tactical-Grade Micro Pod - Infrared-Capable Electro-Optical POD
$34,400.00
Zoom the image with the mouse
Norsat International Inc.
Norsat OPT040CX OPTIVIA Micro Pod
Product Code:
OPT040CX
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.08 KGS
Width:
4.00
(cm)
Height:
8.20
(cm)
Depth:
4.00
(cm)
$19,300.00
| KEY SPECIFICATIONS | |
| Stabilization Accuracy | 0.2mrad (1°/2Hz) (1σ) |
| Standard Preinstalled Components | Visible Light Imaging Wide Field of View (WFOV); Visible Light Imaging Narrow Field of View (NFOV) |
| RF SPECIFICATIONS | |
| Visible Light Fov | 98.5° x 66.3° (WFOV, FL2.4 mm); 30° x 17.1° (NFOV, FL10.36 mm) |
| Visible Light Resolution | 1920×1080@30fps |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | Avg 5W; Peak 8W |
| Power Supply | DC 12 - 16V |
| INTERFACE SPECIFICATIONS | |
| External Interface Communication Interface | TTL |
| External Interface Video Interface | RTSP |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -20°C to +60°C |
| Temperature Storage | -40°C to +60 °C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 82 mm |
| Product Length | 40 mm |
| Product Weight | 0.08 kg |
| Product Width | 40 mm |
| Rotation Range Azimuth | -110° to +110° |
| Rotation Range Elevation | -90° to +30° |
| Volume | Φ: 40 × H: 82 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Harmonized System Code | 8525893900 |
| Unit Package Dimensions | 100 x 100 x 120 mm |
| Unit Package Weight | 2.5 kg |
| Warranty | 1 |
5 customers are viewing this product
Details
| KEY SPECIFICATIONS | |
| Stabilization Accuracy | 0.2mrad (1°/2Hz) (1σ) |
| Standard Preinstalled Components | Visible Light Imaging Wide Field of View (WFOV); Visible Light Imaging Narrow Field of View (NFOV) |
| RF SPECIFICATIONS | |
| Visible Light Fov | 98.5° x 66.3° (WFOV, FL2.4 mm); 30° x 17.1° (NFOV, FL10.36 mm) |
| Visible Light Resolution | 1920×1080@30fps |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | Avg 5W; Peak 8W |
| Power Supply | DC 12 - 16V |
| INTERFACE SPECIFICATIONS | |
| External Interface Communication Interface | TTL |
| External Interface Video Interface | RTSP |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -20°C to +60°C |
| Temperature Storage | -40°C to +60 °C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 82 mm |
| Product Length | 40 mm |
| Product Weight | 0.08 kg |
| Product Width | 40 mm |
| Rotation Range Azimuth | -110° to +110° |
| Rotation Range Elevation | -90° to +30° |
| Volume | Φ: 40 × H: 82 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Harmonized System Code | 8525893900 |
| Unit Package Dimensions | 100 x 100 x 120 mm |
| Unit Package Weight | 2.5 kg |
| Warranty | 1 |
