Norsat International Inc.
Norsat LUMVB050-05 LUMENIX Fully Solid-State Blind-Spot LIDAR
Product Code:
LUMVB050-05
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.50 KGS
Width:
7.00
(cm)
Height:
7.00
(cm)
Depth:
7.00
(cm)
$4,300.00
LUMVB050-05 is a blind-spot LiDAR with a compact size and large FOV, providing real-time per-ception of small objects, close range road participants, and others
| KEY SPECIFICATIONS | |
| Data Rates | 420000 points/sec |
| Horizontal FOV | 140° |
| Horizontal Resolution | 0.5° |
| Laser Wavelength | 940nm |
| Number Of Channels | 150 |
| Operating Range | 50m (30@10% Reflectivity) |
| Ranging Accuracy | ±5cm |
| Ranging Distance | 50m (30@10% Reflectivity) |
| Scanning Frequency | 10 Hz |
| Vertical FOV | 70° |
| Vertical Resolution | 0.5° |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 12W |
| INTERFACE SPECIFICATIONS | |
| Communication Interface | Ethernet |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP67 |
| Laser Safety | Class I (eye safety) |
| Temperature Operational | -40°C to +85°C |
| Temperature Storage | -40℃ - 90℃ |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 70 mm |
| Product Length | 70 mm |
| Product Weight | 0.5 kg |
| Product Width | 70 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.9 kg |
| Aluminium Total Value | $ 2.25 |
| Country Of Origin | Made in China |
| ECCN Number | 5A992 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 9015109000 |
| Warranty | 1 year |
