Norsat LUMVA300-03 LUMENIX Automotive-Grade 192-Line LiDAR
Product Code:
LUMVA300-03
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.60 KGS
Width:
11.20
(cm)
Height:
3.00
(cm)
Depth:
13.60
(cm)
$5,690.00
300 Meter Long-range 192 Line Rotating Mirror LiDAR (Automotive-Grade) Vehicle with vision, we can explore every corner of the earth
| KEY SPECIFICATIONS | |
| Data Rates | 1,536,000 points/s(Single Return); 3,072,000 Points/s(Dual Return) |
| Horizontal FOV | 120° |
| Horizontal Resolution | 0.15°(10Hz) / 0.3°(20Hz) |
| Laser Wavelength | 905nm |
| Number Of Channels | 192 |
| Operating Range | 200m@10% reflectivity |
| Ranging Accuracy | ±5cm |
| Ranging Distance | 200m@10% reflectivity |
| Scanning Frequency | 10Hz/20Hz |
| Vertical FOV | 25° |
| Vertical Resolution | 0.13° |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 15W |
| INTERFACE SPECIFICATIONS | |
| Communication Interface | Automotive Ethernet(1000M Base T1) |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP67, IP6K9K |
| Laser Safety | Class I (eye safety) |
| Temperature Operational | -40°C to +85°C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 30 mm |
| Product Length | 136 mm |
| Product Weight | 0.6 kg |
| Product Width | 112 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.9 kg |
| Aluminium Total Value | $ 2.25 |
| Country Of Origin | Made in China |
| ECCN Number | 5A992 |
| Ex Works | Hong Kong |
| Harmonized System Code | 9015109000 |
| Warranty | 1 year |
