Norsat International Inc.
Norsat LUMRD025-03 LUMENIX Ultra-Thin Anti-Collision LiDAR
Product Code:
LUMRD025-03
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.14 KGS
Width:
5.13
(cm)
Height:
4.29
(cm)
Depth:
5.83
(cm)
$970.00
LUMRD025-03 is a cost-effective and short-range (25m) 2D LiDAR designed specifically for I/O anti-collision functions.
| KEY SPECIFICATIONS | |
| Data Rates | 20160 points/sec |
| Horizontal FOV | 360° |
| Horizontal Resolution | 0.25° |
| Laser Wavelength | 940nm |
| Number Of Channels | 1 |
| Operating Range | 0.05 - 25m (8m@10% Reflectivity) |
| Ranging Accuracy | ±10mm (0.5-5m); ±30mm (Full Range) |
| Ranging Distance | 0.05 - 25m (8m@10%) |
| Scanning Frequency | 14Hz |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 3.7W |
| INTERFACE SPECIFICATIONS | |
| Communication Interface | Ethernet and IO |
| ENVIRONMENTAL SPECIFICATIONS | |
| Electromagnetic Compatibility | GB/T 17626.2-2018 |
| IP Rating | IP65 |
| Laser Safety | Class I (eye safety) |
| Temperature Operational | -20°C to +60°C |
| Temperature Storage | -30℃ - 70℃ |
| Vibration Resistance Standard | GB/T 2423.10-2019 |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 42.9 mm |
| Product Length | 58.3 mm |
| Product Weight | 0.14 kg |
| Product Width | 51.3 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.9 kg |
| Aluminium Total Value | $ 2.25 |
| Country Of Origin | Made in China |
| ECCN Number | 5A992 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 9015109000 |
| Warranty | 1 year |
5 customers are viewing this product
Details
LUMRD025-03 is a cost-effective and short-range (25m) 2D LiDAR designed specifically for I/O anti-collision functions.
| KEY SPECIFICATIONS | |
| Data Rates | 20160 points/sec |
| Horizontal FOV | 360° |
| Horizontal Resolution | 0.25° |
| Laser Wavelength | 940nm |
| Number Of Channels | 1 |
| Operating Range | 0.05 - 25m (8m@10% Reflectivity) |
| Ranging Accuracy | ±10mm (0.5-5m); ±30mm (Full Range) |
| Ranging Distance | 0.05 - 25m (8m@10%) |
| Scanning Frequency | 14Hz |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 3.7W |
| INTERFACE SPECIFICATIONS | |
| Communication Interface | Ethernet and IO |
| ENVIRONMENTAL SPECIFICATIONS | |
| Electromagnetic Compatibility | GB/T 17626.2-2018 |
| IP Rating | IP65 |
| Laser Safety | Class I (eye safety) |
| Temperature Operational | -20°C to +60°C |
| Temperature Storage | -30℃ - 70℃ |
| Vibration Resistance Standard | GB/T 2423.10-2019 |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 42.9 mm |
| Product Length | 58.3 mm |
| Product Weight | 0.14 kg |
| Product Width | 51.3 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.9 kg |
| Aluminium Total Value | $ 2.25 |
| Country Of Origin | Made in China |
| ECCN Number | 5A992 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 9015109000 |
| Warranty | 1 year |
