| KEY SPECIFICATIONS | |
| Accuracy Absolute | 10cm@400m |
| Accuracy Relative | 5mm@100m |
| Camera Effective Pixel | 45MP |
| Camera Scanning Mode | SHARE |
| Laser Data | Seven echo, 2,000,000 Points/Sec |
| Laser Horizontal FOV | 100° |
| Laser Measuring Range | 1500m |
| Laser Range Accuracy | 5mm@100m |
| Laser Scanning Mode | Sing beam |
| Mapping Mode | RTK/PPK |
| POS GNSS Signal Type | GPS L1/L2; GLO L1/L2; GAL E1/E5b; BDS B1/B3/B2a (Supports BeiDou-only Mode) |
| POS Heading Accuracy | 0.010° |
| POS Pitch Accuracy | 0.003° |
| POS Positioning Accuracy Horizontal | ≤0.05m |
| POS Roll Accuracy | 0.003° |
| POS Update Rate | 200 Hz |
| Response Time | real-time |
| ELECTRICAL SPECIFICATIONS | |
| Operating Voltage | 12 - 24V |
| Power Consumption | 55W |
| INTERFACE SPECIFICATIONS | |
| Point Cloud Density | 40pts/㎡@400m@10m/s |
| Processing Storage | Point Cloud Creater |
| Software Mission Planning Software | (Optional) Customized Route Planning Software — WayPoint Master |
| Software Point Cloud Automata | (Optional) PCA software - point cloud classification and post processing software |
| Software Point Cloud Creater | Perpetual license - Self-developed PointCloud Creater software |
| Storage | 64GB, Max suport 25GB TF card |
| Supported Platform | Multi-Rotor Drones, Fixed Wing UAVs, Manned Aircrafts/vehical/Other DIY options available |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -20°C to 55°C |
| Temperature Storage | -40°C to 70°C |
| PHYSICAL SPECIFICATIONS | |
| Material | Aluminum Alloy Body |
| Product Height | 130 mm |
| Product Length | 238 mm |
| Product Weight | 2.5 kg |
| Product Width | 102 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | N/A - No US Content |
| Ex Works | Hong Kong |
| Harmonized System Code | 9015800090 |
| Unit Package Dimensions | 450 x 365 x 200 mm |
| Unit Package Weight | 9 kg |
| Warranty | 1 year |
