| KEY SPECIFICATIONS | |
| Accuracy Absolute | ≤5 cm |
| Accuracy Relative | ≤1 cm |
| Battery Capacity | 11600 mAh |
| Battery Duration | 2h |
| Camera Effective Pixel | 2*20 MP |
| Camera Scanning Mode | SHARE |
| Laser Data | Single echo, 200,000 Points/Sec |
| Laser Horizontal FOV | 360° |
| Laser Measuring Range | 40m |
| Laser Range Accuracy | ±1.5cm |
| Laser Scanning Mode | Hybrid Solid-State Laser Radar |
| Laser Vertical FOV | -7° - 52° |
| Mapping Mode | SLAM; RTK-SLAM; PPK-SLAM |
| Operating Time | 2 - 2.5h |
| POS GNSS Signal Type | GPS L1/L2; GLO L1/L2; GAL E1/E5b; BDS B1/B3/B2a (Supports BeiDou-only Mode) |
| POS Heading Accuracy | 0.040° |
| POS Pitch Accuracy | 0.015° |
| POS Positioning Accuracy Horizontal | ±0.02m |
| POS Positioning Accuracy Vertical | ±0.03m |
| POS Roll Accuracy | 0.015° |
| POS Update Rate | 200 Hz |
| Response Time | real-time |
| ELECTRICAL SPECIFICATIONS | |
| Operating Voltage | 12 - 20V |
| Power Consumption | <25 W |
| INTERFACE SPECIFICATIONS | |
| Point Cloud Density | The density of points can be adjusted by changing the walking speed. |
| Processing Storage | Point Cloud Creater |
| Real-Time Point Cloud | Support |
| Software Point Cloud Automata | (Optional) PCA software - point cloud classification and post processing software |
| Software Point Cloud Creater | Perpetual license - Self-developed PointCloud Creater software |
| Storage | 128GB MicroSD Card |
| Supported Platform | Handheld/Backpack/Other DIY options available |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -20°C to 55°C |
| Temperature Storage | -40°C to 70°C |
| PHYSICAL SPECIFICATIONS | |
| Material | Aluminum Alloy Body |
| Product Height | 324 mm |
| Product Length | 165 mm |
| Product Weight | 1 kg |
| Product Width | 120 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | N/A - No US Content |
| Ex Works | Hong Kong |
| Harmonized System Code | 9015800090 |
| Unit Package Dimensions | 220 x 350 x 400 mm |
| Unit Package Weight | 5 kg |
| Warranty | 1 year |
