Norsat International Inc.

Norsat LTDC09 OPTIVIA 60mJ Laser Target Designator, 9000m

Name: Norsat LTDC09 OPTIVIA 60mJ Laser Target Designator, 9000m
Brand: Norsat International Inc.
SKU: LTDC09
Price: 112800 USD
Availability: InStock

No reviews yet

Product Code: LTDC09

Condition: New

Availability: 10 - 12 Weeks

Weight: 0.70 KGS

Width: 7.00 (cm)

Height: 5.50 (cm)

Depth: 10.80 (cm)

$112,800.00

RF SPECIFICATIONS
Laser Target Designator Accuracy	± 2m
Laser Target Designator Illumination Frequency	20Hz
Laser Target Designator Optical Axis Instability	≤0.03 mrad (1 sigma, per illumination cycle)
Laser Target Designator Ranging Range	≥200 - 9000m (Visibility ≥10km, 2.3m x 2.3m target, target reflectivity ≥20%) (Ranging shall not be performed on targets within 100m)
Laser Target Designator Wavelength	1064±3nm
Laser Target Designator Beam Divergence	≤0.3 mrad
Laser Target Designator Continuous Ranging Duration	5min(1Hz), 2min(5Hz): 1Hz, ≤5min, rest≥5min; 5Hz, ≤2min, rest≥2min;
Laser Target Designator Illumination Duration	Single-Shot: Single cycle≥25s (interval: ≤15s, 8 cycles); Rapid-Shot: Single cycle: ≥60s (interval: 60s, 2 cycles); After 8 single cycles or 2 rapid cycles, the irradiation interval should be ≥30 minutes.
Laser Target Designator Illumination Range	≥200m - 6000m
Laser Target Designator Laser Energy	60mJ
ELECTRICAL SPECIFICATIONS
Power Consumption	Avg ≤35W; Standby ≤5W; Peak Current ≤4A
Power Supply	DC 22 - 32V (typ 28V)
INTERFACE SPECIFICATIONS
External Interface Communication Interface	RS-422 (Configurable RS232 & TTL Interfaces)
ENVIRONMENTAL SPECIFICATIONS
Temperature Operational	-40°C to +60°C
Temperature Storage	-55°C to +70°C
PHYSICAL SPECIFICATIONS
Product Height	55 mm
Product Length	108 mm
Product Weight	0.7 kg
Product Width	70 mm
Volume	108 x 70 x 55 mm
ADDITIONAL INFORMATION
Country Of Origin	Made in China
ECCN Number	EAR99
Harmonized System Code	9015800090
Unit Package Dimensions	350 x 230 x 280 mm
Unit Package Weight	6.5 kg
Warranty	1
