Norsat International Inc.
Norsat LRFB7300DC OPTIVIA 1535 nm Laser Rangefinder LRFB7300DC
Product Code:
LRFB7300DC
Condition:
New
Availability:
4 - 6 Weeks
Weight:
0.13 KGS
Width:
5.85
(cm)
Height:
4.50
(cm)
Depth:
8.00
(cm)
$3,100.00
| RF SPECIFICATIONS | |
| Laser Rangefinder Accuracy | ±1m |
| Laser Rangefinder Operating Wavelength | 1535nm ± 10nm |
| Laser Rangefinder Ranging Range | ≥20m - 7300m |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | Standby≤1.8W; Operating≤4W |
| Power Supply | DC 10 - 14V (typ 12V） |
| INTERFACE SPECIFICATIONS | |
| External Interface Communication Interface | RS422 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -40°C to +60°C |
| Temperature Storage | -55°C to +70°C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 45 mm |
| Product Length | 80 mm |
| Product Weight | ≤0.125 kg |
| Product Width | 58.5 mm |
| Volume | ≤80 x 58.5 x 45 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Harmonized System Code | 9015800090 |
| Warranty | 1 |
5 customers are viewing this product
Details
| RF SPECIFICATIONS | |
| Laser Rangefinder Accuracy | ±1m |
| Laser Rangefinder Operating Wavelength | 1535nm ± 10nm |
| Laser Rangefinder Ranging Range | ≥20m - 7300m |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | Standby≤1.8W; Operating≤4W |
| Power Supply | DC 10 - 14V (typ 12V） |
| INTERFACE SPECIFICATIONS | |
| External Interface Communication Interface | RS422 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -40°C to +60°C |
| Temperature Storage | -55°C to +70°C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 45 mm |
| Product Length | 80 mm |
| Product Weight | ≤0.125 kg |
| Product Width | 58.5 mm |
| Volume | ≤80 x 58.5 x 45 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Harmonized System Code | 9015800090 |
| Warranty | 1 |
