Norsat International Inc.
Norsat LRFA2500CC OPTIVIA 905 nm Laser Rangefinder LRFA2500CC
Product Code:
LRFA2500CC
Condition:
New
Availability:
4 - 6 Weeks
Weight:
0.05 KGS
Width:
3.75
(cm)
Height:
2.25
(cm)
Depth:
5.05
(cm)
$1,002.00
| RF SPECIFICATIONS | |
| Laser Rangefinder Accuracy | ≤±1m |
| Laser Rangefinder Operating Wavelength | 905nm±5nm |
| Laser Rangefinder Ranging Range | ≥15m-2500m (Large Target) |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | Standby≤1W; Avg≤2W@(5V, 1Hz) |
| Power Supply | DC 4.5 - 5.5V |
| INTERFACE SPECIFICATIONS | |
| External Interface Communication Interface | TTL |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -40°C to +60°C |
| Temperature Storage | -55°C to +70°C |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 22.5 mm |
| Product Length | 50.5 mm |
| Product Weight | ≤0.045 kg |
| Product Width | 37.5 mm |
| Volume | ≤50.5 x 37.5 x 22.5 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Harmonized System Code | 9015800090 |
| Warranty | 1 |
