Norsat LNB-100100 Single-Band Ku-Band PLL LNBF
Product Code:
LNB-100100
Condition:
New
Availability:
10 - 12 Weeks
Weight:
0.00 KGS
Request a quote at Contact@orbitalconnect.com or +1.888.218.9394
| KEY SPECIFICATIONS | |
| Band | Ku-Band |
| Input Frequency Band 1 | 11.7 - 12.75 GHz |
| LO Frequency 1 | 10.75 GHz |
| LO Type | PLL |
| Noise Figure Max | 1.0 dB |
| Number Of Onboard Los | Single-Band |
| Output Frequency Band 1 | 950 - 2000 MHz |
| ANTENNA SPECIFICATIONS | |
| Polarization Selection | Vertical: 11.5 - 14 VDC Horizontal: 16 - 19 VDC |
| RF SPECIFICATIONS | |
| Conversion Gain Typ | 60 dB at -40 to +60℃ |
| Gain Flatness (Over Full Band) | ±1.0 dB typ. |
| Gain Ripple At Per 26Mhz | ±1 dB typ. |
| Image Rejection | 40 dBc min. |
| Input P1db | -25 dBm min. @ 10.50 GHz |
| P1db | - 25 dBm min. @ 10.50 GHz |
| Phase Noise 1Khz Offset Max | -65 dBc/Hz |
| Rejection | -35 dB min. @ 10.5 GHz |
| ELECTRICAL SPECIFICATIONS | |
| Current Consumption | 120 mA max. |
| INTERFACE SPECIFICATIONS | |
| IF Connector | F-Connector |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature Operational | -10 to +60°C |
| Temperature Storage | -55 to +80°C |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in Taiwan |
| ECCN Number | EAR99 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 8517690000 |
| Warranty | 1 year |
