Norsat International Inc.
Norsat LNA-8000SC
Product Code:
LNA-8000SC
Availability:
YES
Weight:
0.43 KGS
Width:
10.00
(cm)
Height:
7.00
(cm)
Depth:
18.00
(cm)
$1,650.00
Norsat’s LNA’s provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard C-Band LNAs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNAs. 8000 Series.
| KEY SPECIFICATIONS | |
| Product Family | 8000 Series |
| Band | C-Band |
| Noise Figure | 30 K |
| Input Frequency - Band 1 | C-Band: 3.40 - 4.20 GHz |
| RF SPECIFICATIONS | |
| Conversion Gain | 50 dBm |
| Gain Variation over operating band | 4.0 dB p-p |
| Input VSWR | 2.2 : 1 |
| Output VSWR | 2.0 : 1 |
| Output P1dB compression point | 5 dBm |
| ELECTRICAL SPECIFICATIONS | |
| Power Requirements | 15 - 24 V |
| Current Drain | 100 mA |
| INTERFACE SPECIFICATIONS | |
| RF Input Connector | CPR 229G waveguide grooved |
| RF Output Connector | S - SMA |
| M & C SPECIFICATIONS | |
| Input Power Port | DC Power via SM or N |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature - Operational | -40 to +60°C |
| Humidity | 0 - 95% |
| PHYSICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 180 x 100 x 70 mm |
| Weight | 425 g |
5 customers are viewing this product
Details
Norsat’s LNA’s provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard C-Band LNAs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNAs. 8000 Series.
| KEY SPECIFICATIONS | |
| Product Family | 8000 Series |
| Band | C-Band |
| Noise Figure | 30 K |
| Input Frequency - Band 1 | C-Band: 3.40 - 4.20 GHz |
| RF SPECIFICATIONS | |
| Conversion Gain | 50 dBm |
| Gain Variation over operating band | 4.0 dB p-p |
| Input VSWR | 2.2 : 1 |
| Output VSWR | 2.0 : 1 |
| Output P1dB compression point | 5 dBm |
| ELECTRICAL SPECIFICATIONS | |
| Power Requirements | 15 - 24 V |
| Current Drain | 100 mA |
| INTERFACE SPECIFICATIONS | |
| RF Input Connector | CPR 229G waveguide grooved |
| RF Output Connector | S - SMA |
| M & C SPECIFICATIONS | |
| Input Power Port | DC Power via SM or N |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature - Operational | -40 to +60°C |
| Humidity | 0 - 95% |
| PHYSICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 180 x 100 x 70 mm |
| Weight | 425 g |
Download
| Download Name | |
| Norsat LNA-8000SC Data Sheet | |
