Norsat International Inc.
Norsat LA118N Line Attenuator
Product Code:
LA118N
Condition:
New
Availability:
4 - 6 Weeks
Weight:
0.14 KGS
Width:
3.50
(cm)
Height:
2.50
(cm)
Depth:
9.00
(cm)
$518.00
Norsat's Line Attenuator allows up to 3A of current and passes 10 MHz Reference Signal. It features a rugged machined aluminum chassis, and is environmentally sealed and moisture resistant.
| KEY SPECIFICATIONS | |
| Band | L-BAND |
| Input Frequency Band 1 | 950 - 2150 MHz |
| INTERFACE SPECIFICATIONS | |
| RF Input Connector | N: Type N Connector (50 Ohm) |
| PHYSICAL SPECIFICATIONS | |
| Product Height | 25 mm |
| Product Length | 90 mm |
| Product Weight | 0.14 kg |
| Product Width | 35 mm |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0.068 kg |
| Aluminium COO | CA |
| Aluminium Total Value | $ 0.17 |
| Country Of Origin | Made in Canada |
| ECCN Number | EAR99 |
| Ex Works | Richmond, BC, Canada |
| Harmonized System Code | 8517690000 |
| Unit Package Dimensions | 90 x 35 x 25 mm |
| Unit Package Height | 25 mm |
| Unit Package Length | 90 mm |
| Unit Package Width | 35 mm |
| Warranty | 3 years |
