Norsat International Inc.
Norsat JM012KA Journey ManPack 0.12m Ka-Band Antenna
Product Code:
JM012KA
Condition:
New
Availability:
10 - 12 Weeks
Weight:
4.00 KGS
$96,300.00
| KEY SPECIFICATIONS | |
| Antenna Category | On the Move |
| Band | Ka-Band |
| Of Onboard Los | Single-Band |
| ANTENNA SPECIFICATIONS | |
| Antenna Aperture | 0.12m |
| Axis Ratio | ≤ 1.5 dB |
| Azimuth Acceleration | 200°/s² |
| Azimuth Velocity | ≥ 200°/s² |
| Elevation Acceleration | 200°/s² |
| Elevation Veolcity | ≥ 200°/s2 |
| Motion Range AZ | 0° - 360° infinity |
| Motion Range EL | 0° - 90° finite |
| Polarization | Circular |
| Sidelobe | First sidelobe ≤ -12 dB |
| RF SPECIFICATIONS | |
| Port Isolation Rx-Tx | 60 dB |
| Port Isolation Tx-Rx | 60 dB |
| Power Capacity | ≥100 W/port |
| Rx Frequency | 17.70 - 21.20 GHz |
| Rx Gain | 26.0dBi+20lg(f/19.45GHz)dBi |
| Rx VSWR | ≤ 1.8 : 1 |
| Tx Frequency | 27.50 - 31.00 GHz |
| Tx Gain | 29.0dBi+20lg(f/29.5GHz)dBi |
| Tx VSWR | ≤ 1.8 : 1 |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 100w |
| Power Supply | 12 - 24VDC, when the voltage change ±10 the system can work normally |
| ENVIRONMENTAL SPECIFICATIONS | |
| Humidity | 95% (20°C) |
| IP Rating | IP65 |
| Temperature Operational | -40°C to +55°C |
| Temperature Storage | -50°C to +70°C |
| PHYSICAL SPECIFICATIONS | |
| Default Cable (Included) | Communication cables, Power supply cables, RF cables, Electrical power cables |
| Default Cable Length | 10m |
| Product Weight | ≤ 4 kg (including 6w BUC, LNB); ≤ 8.5Kg(exclude battery) |
| RMS | Better than 0.2 beam width (R.M.S) |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Ex Works | Hong Kong |
| Harmonized System Code | 8529109090 |
| Warranty | 1 year |
