Norsat International Inc.

Norsat 1000 Series HS1048CN Ku-Band Single-Band LNB

No reviews yet
Product Code: HS1048CN
Availability: YES
Weight: 0.30 KGS
Width: 4.20 (cm)
Height: 4.20 (cm)
Depth: 11.10 (cm)
$484.00

Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ku-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNBs. KU-BAND PLL LNB; 10.95-11.70GHZ; LO: +/-4KHZ; NF: 0.8DB; N-CONN



KEY SPECIFICATIONS
Product Family 1000 Series
Band Ku-Band
LO Type PLL
# of onboard LOs Single-band
LO Stability +/- 4 kHz
Noise Figure 0.8 dB
Input Frequency - Band 1 Ku-Band: 10.95 - 11.70 GHz
Output Frequency 1 L-Band: 950 - 1700 MHz

RF SPECIFICATIONS
LO Frequency 1 10.00 GHz
Phase Noise @ 1KHz offset -70 dBc/Hz
Phase Noise @ 10KHz offset -75 dBc/Hz
Phase Noise @ 100KHz offset -90 dBc/Hz
Conversion Gain 60 dB typ
Gain Variation over operating band ≤ 5 dB p-p
Input VSWR 2.5 : 1
Output VSWR 2.2 : 1
Output P1dB compression point 4 dBm

ELECTRICAL SPECIFICATIONS
Power Requirements 15 - 24 V
Current Drain 300 mA

INTERFACE SPECIFICATIONS
RF Input Connector WR-75 waveguide grooved
RF Output Connector N-50 Ohm

M & C SPECIFICATIONS
LED Indicators None

ENVIRONMENTAL SPECIFICATIONS
Temperature - Operational -40 to +60°C
Temperature - Storage -40 to +60°C

PHYSICAL SPECIFICATIONS
Dimensions (L x W x H) 110 x 42 x 42 mm
Weight 300 g
5 customers are viewing this product
  • Norton Secured
  • TRUSTe Verified
  • Authorized.net
  • Accredited Business
  • Verified by Visa
  • Mastercard SecureCode
Details

Norsat’s Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ku-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry’s leading provider of high performance LNBs. KU-BAND PLL LNB; 10.95-11.70GHZ; LO: +/-4KHZ; NF: 0.8DB; N-CONN



KEY SPECIFICATIONS
Product Family 1000 Series
Band Ku-Band
LO Type PLL
# of onboard LOs Single-band
LO Stability +/- 4 kHz
Noise Figure 0.8 dB
Input Frequency - Band 1 Ku-Band: 10.95 - 11.70 GHz
Output Frequency 1 L-Band: 950 - 1700 MHz

RF SPECIFICATIONS
LO Frequency 1 10.00 GHz
Phase Noise @ 1KHz offset -70 dBc/Hz
Phase Noise @ 10KHz offset -75 dBc/Hz
Phase Noise @ 100KHz offset -90 dBc/Hz
Conversion Gain 60 dB typ
Gain Variation over operating band ≤ 5 dB p-p
Input VSWR 2.5 : 1
Output VSWR 2.2 : 1
Output P1dB compression point 4 dBm

ELECTRICAL SPECIFICATIONS
Power Requirements 15 - 24 V
Current Drain 300 mA

INTERFACE SPECIFICATIONS
RF Input Connector WR-75 waveguide grooved
RF Output Connector N-50 Ohm

M & C SPECIFICATIONS
LED Indicators None

ENVIRONMENTAL SPECIFICATIONS
Temperature - Operational -40 to +60°C
Temperature - Storage -40 to +60°C

PHYSICAL SPECIFICATIONS
Dimensions (L x W x H) 110 x 42 x 42 mm
Weight 300 g
