Norsat International Inc.
Norsat HPA-100008 High Power Amplifier Systems, 2.5-7.5GHz, 57dB Gain, 57dBm Psat, 380V AC
Product Code:
HPA-100008
Condition:
New
Availability:
10 - 12 Weeks
Weight:
200.00 KGS
$0.00
• Wide Band: 2.5-7.5GHz
• Gain: 57dB Min
• Psat Output Power:57dBm Min
• Protection:Over TEM,over voltage, load VSWR protection
• 50 Ohm Matched Input / Output
| KEY SPECIFICATIONS | |
| Control Function | DCU/UDP |
| Monitoring Function | 1,Chip-level: status of power chip(gate voltage, drain current, case-temp); |
| Protection Functions | 1,Over TEM:≥+55℃ shutdown |
| RF SPECIFICATIONS | |
| AC Voltage | 380 VAC typ. , 420 VAC max. |
| ESD Sensitivity(Hbm) | Class 0, passed 150V |
| Gain Flatness | ± 1.5 dB typ |
| Harmonics@Pout=57Dbm | -10 dBc max |
| Impedance | 50 Ohms |
| Input Frequency Band 1 | 2.5-7.5 GHz |
| Input VSWR | 1.5 :1 max |
| Output Psat Min | 57 dBm |
| Power Gain Min | 57 dB |
| RF Input Power | +5 dBm |
| Spurious@Pout=57Dbm | -60 dBc max. |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 500W typ |
| INTERFACE SPECIFICATIONS | |
| Communication Connector | RJ45 |
| Forward / Reverse Coupling | N Female/ N Female |
| Input/ Output Connector | N Female/WRD250D30 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Altitude | 10,000 feet |
| Relative Humidity | 95% |
| Shock(Non Operating) | 20G for 11msc half sine wave, 3 axis both directions |
| Shock/Vibration(MIL-STD-810F) | 25g rms (15 degree 2KHz) endurance, 1 hour per axis |
| Temperature Operational | -20°C to +50°C |
| Temperature Storage | -50°C to +70°C |
| PHYSICAL SPECIFICATIONS | |
| Cooling | Built in Cooling system, forced air cooling |
| Product Weight | 200 kg max |
| Size | 19 Inch 20U*500 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Ex Works | Hong Kong |
| Harmonized System Code | 8517799000 |
| Unit Package Dimensions | N/A |
| Unit Package Weight | N/A |
5 customers are viewing this product
Details
• Wide Band: 2.5-7.5GHz
• Gain: 57dB Min
• Psat Output Power:57dBm Min
• Protection:Over TEM,over voltage, load VSWR protection
• 50 Ohm Matched Input / Output
| KEY SPECIFICATIONS | |
| Control Function | DCU/UDP |
| Monitoring Function | 1,Chip-level: status of power chip(gate voltage, drain current, case-temp); |
| Protection Functions | 1,Over TEM:≥+55℃ shutdown |
| RF SPECIFICATIONS | |
| AC Voltage | 380 VAC typ. , 420 VAC max. |
| ESD Sensitivity(Hbm) | Class 0, passed 150V |
| Gain Flatness | ± 1.5 dB typ |
| Harmonics@Pout=57Dbm | -10 dBc max |
| Impedance | 50 Ohms |
| Input Frequency Band 1 | 2.5-7.5 GHz |
| Input VSWR | 1.5 :1 max |
| Output Psat Min | 57 dBm |
| Power Gain Min | 57 dB |
| RF Input Power | +5 dBm |
| Spurious@Pout=57Dbm | -60 dBc max. |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 500W typ |
| INTERFACE SPECIFICATIONS | |
| Communication Connector | RJ45 |
| Forward / Reverse Coupling | N Female/ N Female |
| Input/ Output Connector | N Female/WRD250D30 |
| ENVIRONMENTAL SPECIFICATIONS | |
| Altitude | 10,000 feet |
| Relative Humidity | 95% |
| Shock(Non Operating) | 20G for 11msc half sine wave, 3 axis both directions |
| Shock/Vibration(MIL-STD-810F) | 25g rms (15 degree 2KHz) endurance, 1 hour per axis |
| Temperature Operational | -20°C to +50°C |
| Temperature Storage | -50°C to +70°C |
| PHYSICAL SPECIFICATIONS | |
| Cooling | Built in Cooling system, forced air cooling |
| Product Weight | 200 kg max |
| Size | 19 Inch 20U*500 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | EAR99 |
| Ex Works | Hong Kong |
| Harmonized System Code | 8517799000 |
| Unit Package Dimensions | N/A |
| Unit Package Weight | N/A |
