Norsat International Inc.
| ANTENNA SPECIFICATIONS | |
| ACU Size | 313*192*44 |
| Angle Display Resolution | 0.1 degrees |
| Angle Display Range Elevation | 3° to 110° (Hardware); 3° to 80° (Software) |
| Angle Display Range Elevation Azimuth | 690° |
| Antenna Aperture | 0.45 m |
| Antenna Drive Mode | Auto Tracking |
| Antenna Input Power | 30V DC, RX/TX port total 5.0A max |
| Antenna Type | KA-90 |
| Auto Acquisition | Yes |
| Auto Acquistion Time | 5 minutes Max. |
| Azimuth Range | 690° |
| Azimuth Speed | 10º/sec |
| Dish Diameter | 0.45 M |
| Elevation Range | 3° to 110° (Hardware); 3° to 80° (Software) |
| Elevation Speed | 10º/sec |
| External I/O | Mini-USB, Console, Ethernet, Wi-fi |
| Feed Configuration | Ring focus |
| Gyro Interface | NMEA 0183 |
| Motion Range AZ | ±8° at 15-20 sec periods |
| Motion Range EL | ±10° at 6-12 sec periods |
| Motion Range POL | ±20° at 8-12 sec periods |
| Operating Platform | 3-Axis |
| Polarization | Linear |
| Polarization Range | ±90º |
| Polarization Speed | 5º/sec |
| Preset Satellite | 80 satellites |
| Ship Motion Pitch | ±10° at 6-12 sec periods |
| Ship Motion Roll | ±20° at 8-12 sec periods |
| Ship Motion Yaw | ±8° at 15-20 sec periods |
| Skew Control | Automatic |
| Standard LNB Options | Quad / Quattro LNB |
| RF SPECIFICATIONS | |
| G/T | Minimum EIRP; 48dbW |
| LNB Reference Type | Internal |
| INTERFACE SPECIFICATIONS | |
| Dvb Tuner | DVB-S2 |
| Openbmip | None |
| ENVIRONMENTAL SPECIFICATIONS | |
| Humidity | Up to 100% @ 40°C |
| Temperature Operational | -20°C to +55°C |
| Temperature Survival | -20°C to +55°C |
| PHYSICAL SPECIFICATIONS | |
| Product Dimensions Height | 530 mm |
| Product Dimensions Length | 510 mm |
| Product Dimensions Width | 510 mm |
| Product Weight | 11.5 kg |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 5.75 kg |
| Aluminium COO | KR |
| Aluminium Total Value | $14.375 |
| Country Of Origin | Made in Republic of Korea |
| Ex Works | Hong Kong |
| Harmonized System Code | 8529109200 |
| Number Of Packages | 1 |
| Unit Package Dimensions Height | 700 mm |
| Unit Package Dimensions Length | 590 mm |
| Unit Package Dimensions Width | 590 mm |
| Unit Package Weight | 24 kg |
| Warranty | 1 year |
