Norsat International Inc.
Norsat AFP178050 AQUARA Flying Platform Drone
Product Code:
AFP178050
Condition:
New
Availability:
10 - 12 Weeks
Weight:
58.00 KGS
$120,400.00
| KEY SPECIFICATIONS | |
| Ceiling | 5000 m |
| Control Distance | 10 km |
| Cruising Speed | 0 - 10 m/s |
| Full Load Life | 18 min |
| Maximum Taking-Off Weight | 110 kg |
| No-Load Life | 45 min |
| Sea Level Climbing Speed | 0 - 5 m/s |
| ELECTRICAL SPECIFICATIONS | |
| Standard Charger | One charge |
| Standard Smart Battery | (30000mAh x 16S) x 3 pieces |
| INTERFACE SPECIFICATIONS | |
| RTK | Standard RTK module (Network RTK, free for the first year, additional charge from the second year) |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP54 |
| Temperature Operational | -20°C to -50°C |
| Wind Resistance | 12m/s (Level 6) |
| Working Humidity | 10% - 90% |
| PHYSICAL SPECIFICATIONS | |
| Material | Composite carbon fiber, Aviation aluminum |
| Maximum Load | 50 kg |
| Product Dimensions Height | 950 mm |
| Product Weight | <58 kg |
| Wheelbase | 1780 mm |
| Wing Type | Four axes and eight OARS |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | Not Applicable |
| Ex Works | Hong Kong |
5 customers are viewing this product
Details
| KEY SPECIFICATIONS | |
| Ceiling | 5000 m |
| Control Distance | 10 km |
| Cruising Speed | 0 - 10 m/s |
| Full Load Life | 18 min |
| Maximum Taking-Off Weight | 110 kg |
| No-Load Life | 45 min |
| Sea Level Climbing Speed | 0 - 5 m/s |
| ELECTRICAL SPECIFICATIONS | |
| Standard Charger | One charge |
| Standard Smart Battery | (30000mAh x 16S) x 3 pieces |
| INTERFACE SPECIFICATIONS | |
| RTK | Standard RTK module (Network RTK, free for the first year, additional charge from the second year) |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP54 |
| Temperature Operational | -20°C to -50°C |
| Wind Resistance | 12m/s (Level 6) |
| Working Humidity | 10% - 90% |
| PHYSICAL SPECIFICATIONS | |
| Material | Composite carbon fiber, Aviation aluminum |
| Maximum Load | 50 kg |
| Product Dimensions Height | 950 mm |
| Product Weight | <58 kg |
| Wheelbase | 1780 mm |
| Wing Type | Four axes and eight OARS |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | Not Applicable |
| Ex Works | Hong Kong |
