            | KEY SPECIFICATIONS | |
| Equipped | Thrower, broken window fire bomb, water-based fire bomb, dry powder fire tank, high-altitude fire hose |
| Flight Altitude | ≥1000 m |
| Flight Speed | ≥20 m/s max |
| Full-Load Life | ≥ 16 min (load weight 50 kg) |
| No-Load Life | ≥45 min (no wind environment) |
| Wind Resistance Grade | ≥6 |
| ELECTRICAL SPECIFICATIONS | |
| Fpv Camera | With 4-in-1 link, integrated 8W searchlight, ultra-high luminous efficiency LED, and 150° lens |
| INTERFACE SPECIFICATIONS | |
| Flight Mode Switching | Manual flight mode, satellite mode (hover), route flight mode, and ground station can effectively fire and control the airborne mission module |
| Ground Station Firing Control | The ground station can carry out effective firing control of the airborne mission module |
| Handheld Ground Control Station | Industrial-grade handheld ground control station with 7-inch HD screen equipped with automatic flight control software |
| Positioning Accuracy | ±50 cm/10 |
| Positioning System | GPS |
| Security System | With identity identification, secret key flight, background data supervision |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP Rating | IP55 |
| Temperature Resistance | ≥50°C |
| PHYSICAL SPECIFICATIONS | |
| Arm Weight | ≥5 kg |
| Battery Weight | at least 9 kg |
| Empty Weight | ≥54 kg |
| Fold Product Height | 850 mm |
| Fold Product Length | 860 mm |
| Fold Product Width | 860 mm |
| Fuselage Protection Level | ≥ip55 |
| Maximum Load | ≥50 kg |
| Maximum Takeoff Weight | ≥110 kg |
| Number Of Arms | ≥4 |
| Product Weight | ≥54 kg |
| Propeller | 41 inch paddle |
| Unfold Product Height | 930 mm |
| Unfold Product Length | 1240 mm |
| Unfold Product Width | 1240 mm |
| Wheelbase | ≤1648 mm |
| ADDITIONAL INFORMATION | |
| Country Of Origin | Made in China |
| ECCN Number | Not Applicable |
| Ex Works | Hong Kong |
