KEY SPECIFICATIONS | |
Equipped | Thrower, broken window fire bomb, water-based fire bomb, dry powder fire tank, high-altitude fire hose |
Flight Altitude | ≥1000 m |
Flight Speed | ≥20 m/s max |
Full-Load Life | ≥ 16 min (load weight 50 kg) |
No-Load Life | ≥45 min (no wind environment) |
Wind Resistance Grade | ≥6 |
ELECTRICAL SPECIFICATIONS | |
Fpv Camera | With 4-in-1 link, integrated 8W searchlight, ultra-high luminous efficiency LED, and 150° lens |
INTERFACE SPECIFICATIONS | |
Flight Mode Switching | Manual flight mode, satellite mode (hover), route flight mode, and ground station can effectively fire and control the airborne mission module |
Ground Station Firing Control | The ground station can carry out effective firing control of the airborne mission module |
Handheld Ground Control Station | Industrial-grade handheld ground control station with 7-inch HD screen equipped with automatic flight control software |
Positioning Accuracy | ±50 cm/10 |
Positioning System | GPS |
Security System | With identity identification, secret key flight, background data supervision |
ENVIRONMENTAL SPECIFICATIONS | |
IP Rating | IP55 |
Temperature Resistance | ≥50°C |
PHYSICAL SPECIFICATIONS | |
Arm Weight | ≥5 kg |
Battery Weight | at least 9 kg |
Empty Weight | ≥54 kg |
Fold Product Height | 850 mm |
Fold Product Length | 860 mm |
Fold Product Width | 860 mm |
Fuselage Protection Level | ≥ip55 |
Maximum Load | ≥50 kg |
Maximum Takeoff Weight | ≥110 kg |
Number Of Arms | ≥4 |
Product Weight | ≥54 kg |
Propeller | 41 inch paddle |
Unfold Product Height | 930 mm |
Unfold Product Length | 1240 mm |
Unfold Product Width | 1240 mm |
Wheelbase | ≤1648 mm |
ADDITIONAL INFORMATION | |
Country Of Origin | Made in China |
ECCN Number | Not Applicable |
Ex Works | Hong Kong |
