Norsat ACS240KA-A Single Speed Integrated Antenna Controller for 2.4m Ka-Band Earth Station
Antenna control systems are supplied only for Motorized Earth Station Antennas. Please select the "Motorized" drive mode for Recommended Combinations below. Manual Earth Stations do NOT require a control system.
To select the correct Anchor Earth Station Antenna model for the control system, please refer to the corresponding antenna aperture, band, and drive mode.
For example, ACS240KA-A is compatible with ESER240KA2A.
| KEY SPECIFICATIONS | |
| Antenna Aperture | 2.4m |
| Band | Ka-Band |
| Drive Speed | Constant Speed |
| Structural Form | single-speed integrated |
| ANTENNA SPECIFICATIONS | |
| Angle Display Resolution | 0.01° |
| Angle Display Range | 0 - 360° |
| Encoder Accuracy AZ | 0.04° (optional: 0.01°) |
| Encoder Accuracy EL | 0.04° (optional: 0.01°) |
| Encoder Accuracy POL | 0.08° (optional: 0.04°) |
| Preset Satellite | 10 satellites |
| Tracking Accuracy | 1/10 reception beamwidth |
| Type | Single speed integrated antenna controller |
| ELECTRICAL SPECIFICATIONS | |
| Power Consumption | 3000W |
| Power Supply | AC 380V±10%, 50/60Hz |
| INTERFACE SPECIFICATIONS | |
| Remote Interface | RJ-45 network |
| ENVIRONMENTAL SPECIFICATIONS | |
| Safety | 1.Soft and hard limits provide guarantee for the safe operation of the antenna; 2.The cables are all flame retardant series cables -10 - 50℃; (optional low temperature cables -30 - 90℃ |
| Temperature Operational | 0°C to +40°C |
| Temperature Operational Cable | -10 - 60℃; low-temperature cable: -30 - 90℃ |
| PHYSICAL SPECIFICATIONS | |
| Product Dimension | 19inch/3U |
| Standard Configuration | Antenna control unit, antenna drive unit, beacon tracking receiving unit, photoelectric encoder, flame retardant cable and connectors |
| ADDITIONAL INFORMATION | |
| Aluminium Content | 0 Kg |
| Aluminium Total Value | $ 0 |
| Country Of Origin | Made in China |
| ECCN Number | 5A991.B |
| Ex Works | Hong Kong |
| Harmonized System Code | 8529109090 |
| Warranty | 1 year |
