Norsat 9500HBC-3F 9000H-3 Dual-Band Ka-Band PLL LNB
Product Code:
9500HBC-3F
Weight:
0.50 KGS
Width:
13.30
(cm)
Height:
3.90
(cm)
Depth:
7.00
(cm)
$2,811.00
| KEY SPECIFICATIONS | |
| band | Ka-Band |
| input frequency band 1 | 19.20 - 20.20 GHz |
| input frequency band 2 | 20.20 - 21.20 GHz |
| LO frequency 1 | 18.25 GHz |
| LO frequency 2 | 19.25 GHz |
| LO stability | ±50 kHz |
| LO type | PLL |
| noise figure max | 1.6 dB |
| noise figure typ | 1.3 dB |
| number of onboard LOs | Dual-Band |
| output frequency band 1 | 950 - 1950 MHz |
| output frequency band 2 | 950 - 1950 MHz |
| Product Revision | A |
| RF SPECIFICATIONS | |
| control signal 1 | 13V / No Tone |
| control signal 2 | 18V / No Tone |
| conversion gain max | 65 dB |
| conversion gain min | 55 dB |
| conversion gain typ | 58 dB |
| Gain Flatness (over full band) | 4 dB p-p |
| image rejection | 40 dBc min. |
| input VSWR | 2.2 : 1 max. |
| output P1dB | 5 dBm min. |
| output VSWR | 2.0 : 1 max. |
| phase noise 100Hz offset max | -60 dBc/Hz |
| phase noise 100kHz offset max | -90 dBc/Hz |
| phase noise 10kHz offset max | -80 dBc/Hz |
| phase noise 1kHz offset max | -70 dBc/Hz |
| spurious | -60 dBc (in band) ; -50 dBc (out of band) |
| ELECTRICAL SPECIFICATIONS | |
| current consumption | 350 mA |
| power requirements | +12 to +19V DC |
| INTERFACE SPECIFICATIONS | |
| IF connector | F-Connector |
| RF input connector | WR-42 waveguide grooved |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP rating | IP 67 |
| temperature operational | -40 to +60°C |
| PHYSICAL SPECIFICATIONS | |
| product dimensions (LxWxH) | 133 x 70 x 39 mm |
| product weight | 0.5 kg |
5 customers are viewing this product
Details
| KEY SPECIFICATIONS | |
| band | Ka-Band |
| input frequency band 1 | 19.20 - 20.20 GHz |
| input frequency band 2 | 20.20 - 21.20 GHz |
| LO frequency 1 | 18.25 GHz |
| LO frequency 2 | 19.25 GHz |
| LO stability | ±50 kHz |
| LO type | PLL |
| noise figure max | 1.6 dB |
| noise figure typ | 1.3 dB |
| number of onboard LOs | Dual-Band |
| output frequency band 1 | 950 - 1950 MHz |
| output frequency band 2 | 950 - 1950 MHz |
| Product Revision | A |
| RF SPECIFICATIONS | |
| control signal 1 | 13V / No Tone |
| control signal 2 | 18V / No Tone |
| conversion gain max | 65 dB |
| conversion gain min | 55 dB |
| conversion gain typ | 58 dB |
| Gain Flatness (over full band) | 4 dB p-p |
| image rejection | 40 dBc min. |
| input VSWR | 2.2 : 1 max. |
| output P1dB | 5 dBm min. |
| output VSWR | 2.0 : 1 max. |
| phase noise 100Hz offset max | -60 dBc/Hz |
| phase noise 100kHz offset max | -90 dBc/Hz |
| phase noise 10kHz offset max | -80 dBc/Hz |
| phase noise 1kHz offset max | -70 dBc/Hz |
| spurious | -60 dBc (in band) ; -50 dBc (out of band) |
| ELECTRICAL SPECIFICATIONS | |
| current consumption | 350 mA |
| power requirements | +12 to +19V DC |
| INTERFACE SPECIFICATIONS | |
| IF connector | F-Connector |
| RF input connector | WR-42 waveguide grooved |
| ENVIRONMENTAL SPECIFICATIONS | |
| IP rating | IP 67 |
| temperature operational | -40 to +60°C |
| PHYSICAL SPECIFICATIONS | |
| product dimensions (LxWxH) | 133 x 70 x 39 mm |
| product weight | 0.5 kg |
