Norsat International Inc.

Norsat 9000LIBN 9000 Single-Band Ka-Band DRO LNB with Isolator

No reviews yet
Product Code: 9000LIBN
Weight: 0.30 KGS
Width: 11.10 (cm)
Height: 4.20 (cm)
Depth: 4.20 (cm)
$644.00
KEY SPECIFICATIONS
band Ka-Band
input frequency band 1 19.20 - 20.20 GHz
LO frequency 1 17.25 GHz
LO stability ±2 kHz
LO type DRO
noise figure max 1.2 dB
noise figure typ 1.5 dB
number of onboard LOs Single-Band
output frequency band 1 950 - 1950 MHz
Product Revision A
RF SPECIFICATIONS
conversion gain max 65 dB
conversion gain min 55 dB
conversion gain typ 60 dB
Gain Flatness (over full band) ≤ 5 dB p-p max.
gain flatness ripple ≤ 5 dB p-p
input VSWR 2.5 : 1 max.
output P1dB + 3 dBm min.
output VSWR 2.5 : 1 max.
phase noise 100kHz offset max -95 dBc/Hz
phase noise 10kHz offset max -75 dBc/Hz
phase noise 1kHz offset max -60 dBc/Hz
ELECTRICAL SPECIFICATIONS
power requirements +12 to +24V DC
INTERFACE SPECIFICATIONS
IF connector N-Connector
isolator With Isolator
RF input connector WR-42 waveguide grooved
ENVIRONMENTAL SPECIFICATIONS
temperature operational -30 to +60°C
temperature storage -40 to +80°C
PHYSICAL SPECIFICATIONS
product dimensions (LxWxH) 111 x 42 x 42 mm
product weight 0.3 kg
