Norsat 9000 Series 9000HAN-2 Ka-Band Single-Band LNB
Product Code:
9000HAN-2
Availability:
YES
Weight:
0.35 KGS
Width:
4.20
(cm)
Height:
4.20
(cm)
Depth:
11.10
(cm)
$1,126.00
Norsats Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ka-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industrys leading provider of high performance LNBs. KA-BAND PLL LNB; 18.2-19.2GHZ; LO: +/-60KHZ; NF 1.8DB; N-CONN
| KEY SPECIFICATIONS | |
| Product Family | 9000 Series |
| Band | Ka-Band |
| LO Type | PLL |
| # of onboard LOs | Single-band |
| LO Stability | +/- 60 kHz |
| Noise Figure | 1.5dB |
| Input Frequency - Band 1 | Ka-Band: 18.20 - 19.20 GHz |
| Output Frequency 1 | L-Band: 950 - 1950 MHz |
| RF SPECIFICATIONS | |
| LO Frequency 1 | 17.25 GHz |
| Phase Noise @ 1KHz offset | -75 dBc/Hz |
| Phase Noise @ 10KHz offset | -80 dBc/Hz |
| Phase Noise @ 100KHz offset | -100 dBc/Hz |
| Conversion Gain | 55 dB typ |
| Gain Variation over operating band | 4.0 dB p-p |
| Gain Variation over temperature | 5 dB max (-40°C to +60°C) |
| Input VSWR | 2.2 : 1 |
| Output VSWR | 2.0 : 1 |
| Output P1dB compression point | 3 dBm |
| ELECTRICAL SPECIFICATIONS | |
| Power Requirements | 15 - 24 V |
| Current Drain | 160 mA |
| INTERFACE SPECIFICATIONS | |
| RF Input Connector | WR-42 waveguide grooved |
| RF Output Connector | N-50 Ohm |
| M & C SPECIFICATIONS | |
| LED Indicators | None |
| ENVIRONMENTAL SPECIFICATIONS | |
| Temperature - Operational | -40 to +60°C |
| PHYSICAL SPECIFICATIONS | |
| Dimensions (L x W x H) | 111 x 42 x 42 mm |
| Weight | 350 g |
