Norsat International Inc.
Norsat 4000 Series 4107CF Ku-Band Single-Band LNB
Product Code:
4107CF
Availability:
YES
Weight:
0.20 KGS
Width:
4.30
(cm)
Height:
4.30
(cm)
Depth:
8.50
(cm)
$128.00
Norsat's Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ku-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry's leading provider of high performance LNBs. KU-BAND PLL LNB; 10.95-11.70GHZ; LO: +/-150KHZ; NF: 0.7DB; F-CONN
| KEY SPECIFICATIONS | ||
| Band | Ku-Band | |
| Input Frequency Band 1 | Ku-Band: 10.95 - 11.70 GHz | |
| Lo Stability | ±150 kHz | |
| Lo Type | PLL | |
| Noise Figure | 0.7 dB | |
| Output Frequency 1 | L-Band: 950 - 1700 MHz | |
| RF SPECIFICATIONS | ||
| Conversion Gain | 60 dB typ | |
| Input VSWR | 2.5: 1 | |
| LO Frequency 1 | 10.00 GHz | |
| Output VSWR | 2.5: 1 | |
| ELECTRICAL SPECIFICATIONS | ||
| Power Requirements | 15 - 24 V | |
| INTERFACE SPECIFICATIONS | ||
| RF Input Connector | WR-75 waveguide grooved | |
| RF Output Connector | F-75 Ohm | |
| RF SPECIFICATIONS | ||
| RF Input Connector | WR-75 waveguide grooved | |
| RF Output Connector | F-75 Ohm | |
| ENVIRONMENTAL SPECIFICATIONS | ||
| Temperature Operational | -40 to +60°C | |
| Temperature Storage | -40 to +80°C | |
| Weight | 200g | |
| PHYSICAL SPECIFICATIONS | ||
| Dimensions (LxWxH) | 85 x 43 x 43 mm | |
5 customers are viewing this product
Details
Norsat's Low Noise Blocks (LNBs) provide signal reception for satellite communications around the world. We offer premium performance and reliability in the smallest form factor possible. All of our standard Ku-Band LNBs are backed by a 3 year warranty and nearly forty years of experience as the industry's leading provider of high performance LNBs. KU-BAND PLL LNB; 10.95-11.70GHZ; LO: +/-150KHZ; NF: 0.7DB; F-CONN
| KEY SPECIFICATIONS | ||
| Band | Ku-Band | |
| Input Frequency Band 1 | Ku-Band: 10.95 - 11.70 GHz | |
| Lo Stability | ±150 kHz | |
| Lo Type | PLL | |
| Noise Figure | 0.7 dB | |
| Output Frequency 1 | L-Band: 950 - 1700 MHz | |
| RF SPECIFICATIONS | ||
| Conversion Gain | 60 dB typ | |
| Input VSWR | 2.5: 1 | |
| LO Frequency 1 | 10.00 GHz | |
| Output VSWR | 2.5: 1 | |
| ELECTRICAL SPECIFICATIONS | ||
| Power Requirements | 15 - 24 V | |
| INTERFACE SPECIFICATIONS | ||
| RF Input Connector | WR-75 waveguide grooved | |
| RF Output Connector | F-75 Ohm | |
| RF SPECIFICATIONS | ||
| RF Input Connector | WR-75 waveguide grooved | |
| RF Output Connector | F-75 Ohm | |
| ENVIRONMENTAL SPECIFICATIONS | ||
| Temperature Operational | -40 to +60°C | |
| Temperature Storage | -40 to +80°C | |
| Weight | 200g | |
| PHYSICAL SPECIFICATIONS | ||
| Dimensions (LxWxH) | 85 x 43 x 43 mm | |
