Globalstar
Globalstar ST150M RF Module - Default Version
Product Code:
1850-0407-01
Condition:
New
Availability:
YES
Weight:
0.01 KGS
Width:
2.80
(cm)
Height:
0.40
(cm)
Depth:
5.08
(cm)
$149.00
Take your satellite asset tracking and data management solutions to the next level with the ST150M. Engineered with open source common architecture, the ST150M offers a simplified design with the latest hardware and software capabilities to support the most demanding development requirements.
Globalstar’s Application Enablement Platform offers ST150M users the utility for a wide range of applications, empowering rapid development and customization of firmware for more advanced smart data applications by enabling AI at the edge.
ST150M satellite modem module helps partners create new products in a fraction of normal development time and cost. The module includes a GPS receiver, accelerometer, Nordic MCU, 8MB external flash memory, integrated voltage regulator and BLE tranceiver. Its low-power architecture allows integrators to minimize battery requirements. An ST150 Dev Kit provides an ST150M module on a dev board with satellite and GPS patch antennas, all mounted on an Arduino Shield, to develop and test technology designs before committing them to hardware.
Key Features
All applications of Integrity 150
Lower entry barriers for custom applications
Modular library layer can be easily included/excluded
Rich application examples allow for faster development
Easy provisioning, connectivity, and configuration
Proprietary secure Bluetooth protocol
Connecting sensors and edge computing solutions to the device is easy and allows for the transportation of a wealth of data and critical information
Industry supported Language Application Base
Embedded benefits
Very low power consumption
Full modular certification
Unprecedented payload options
PTP (Previous Track Point)
Specifications
- Built in programming headers
- I2C
- Vin - 3.3 Vdc Iin - 100 ma Max
- VRFin - 3.3 VdcIRFin - 500 ma Max
- VUSB - 5.0 Vdc
- Operation and Storage: -40 °F to 185 °F (-40 °C to 85 °C)
DIMENSIONS
1.10” (H) X 2” (W) X 0.16” (D)
28mm (H) X 50.8mm (W) X 4 mm (D)
WEIGHT
Approx. 0.27 oz (7.6 g) with shield
5 customers are viewing this product
Details
Take your satellite asset tracking and data management solutions to the next level with the ST150M. Engineered with open source common architecture, the ST150M offers a simplified design with the latest hardware and software capabilities to support the most demanding development requirements.
Globalstar’s Application Enablement Platform offers ST150M users the utility for a wide range of applications, empowering rapid development and customization of firmware for more advanced smart data applications by enabling AI at the edge.
ST150M satellite modem module helps partners create new products in a fraction of normal development time and cost. The module includes a GPS receiver, accelerometer, Nordic MCU, 8MB external flash memory, integrated voltage regulator and BLE tranceiver. Its low-power architecture allows integrators to minimize battery requirements. An ST150 Dev Kit provides an ST150M module on a dev board with satellite and GPS patch antennas, all mounted on an Arduino Shield, to develop and test technology designs before committing them to hardware.
Key Features
All applications of Integrity 150
Lower entry barriers for custom applications
Modular library layer can be easily included/excluded
Rich application examples allow for faster development
Easy provisioning, connectivity, and configuration
Proprietary secure Bluetooth protocol
Connecting sensors and edge computing solutions to the device is easy and allows for the transportation of a wealth of data and critical information
Industry supported Language Application Base
Embedded benefits
Very low power consumption
Full modular certification
Unprecedented payload options
PTP (Previous Track Point)
Specifications
- Built in programming headers
- I2C
- Vin - 3.3 Vdc Iin - 100 ma Max
- VRFin - 3.3 VdcIRFin - 500 ma Max
- VUSB - 5.0 Vdc
- Operation and Storage: -40 °F to 185 °F (-40 °C to 85 °C)
DIMENSIONS
1.10” (H) X 2” (W) X 0.16” (D)
28mm (H) X 50.8mm (W) X 4 mm (D)
WEIGHT
Approx. 0.27 oz (7.6 g) with shield
